Ingke YKJD-8008NL 100% compatible 7499010211A WE Industrial RJ45 connector jacks
Pulse Part Number : 7499010211A
Made in China:YKJD-8008NL
Original Manufacturer:Ingke Technology
Supply Ability:5500K-PCS/Month
Product Category: Modular Connectors / Ethernet Connectors
Packaging :Tray
Connector Type: RJ45
Number of Ports :1
Number of Rows :1
Applications : 10/100 Base-T, AutoMDIX
Mounting Type : Through Hole
Orientation: 90°Angle(Right)
Termination :Solder
LED Color: Green - Yellow
Number of Cores per Jack : 4
Shielding : Shielded
Features: Board Guide
Tab Direction : Down
Contact Material : Phosphor Bronze
Contact Finish : Gold
Operating Temperature : -40℃~85℃
Contact Finish Thickness : 15µin (0.38µm)
Flammability Rating: UL 94 V-0
Shield Material : Copper Alloy
Housing Material : Thermoplastic
Manufacturer: Ingke Technology Co.,Ltd
INGKE can provide 3D model for engineers' design
Our service:
1).Free sample is available!
2).OEM & ODM orders are welcomed.
3).We offer after-sale service for 8 years.
Our Advantage:
1).High-quality，OEM factory for RJ45 Connector more than 10 years.
2).Cost reduction, lead time within 1 week, FREE samples.
3).After sales services 24*7 to help you solve any kind of problems
Ingke Technology Mass production of the following models;
7499111446 7499111221A 7499111447 7499151120 7497110616 7499010121A 7499011121A 74990100011A
7499011222A 7499010211A 74990111217 7499010441 74990112116A 7499410213 7499111001A 7498111120R
7498111120R 7498111120R 74991101227498011211 7499021125 7499110124 7499411122 7499511440 7499210123
7499511611A 7499011001A 7499010001A 7499011002 7499211123 7499611421 7499311611 7499010003A
74990101212 7498210220A 7497011611A 7498210002 7498210002 7498210002 7499211122A 7499121211
7499210124A 7499111000A 7499051002 7499410420 7497111611A 7499511610 7498011001A 7499010004A
7498011008 7499211002A 74990101241 7499010126A 7499410221 7499021002A 7498210003
7499210123A
74990110013 7499210001A 7499021121 7499111614A 7499111005 7499511001A 7499011122A 7499211123A
