J0011D01BNL 10/100 Base-T, AutoMDIX Through Hole RJ45 Magjack Connectors

Ingke YKJD-8008NL 100% compatible J0011D01BNL Pulse RJ45 Magjack Connectors

Pulse Part Number : J0011D01BNL

Made in China:YKJD-8008NL

Original Manufacturer:Ingke Technology

Supply Ability:5500K-PCS/Month

Product Category: Modular Connectors / Ethernet Connectors

Packaging :Tray

Connector Type: RJ45

Number of Ports :1

Number of Rows :1

Applications : 10/100 Base-T, AutoMDIX

Mounting Type : Through Hole

Orientation: 90°Angle(Right)

Termination :Solder

LED Color: Green - Yellow

Number of Cores per Jack : 4

Shielding : Shielded

Features:  Board Guide

Tab Direction : Down

Contact Material : Phosphor Bronze

Contact Finish : Gold

Operating Temperature : -40℃~85℃

Contact Finish Thickness : 15µin (0.38µm)

Flammability Rating: UL 94 V-0

Shield Material : Copper Alloy

Housing Material : Thermoplastic

Manufacturer: Ingke Technology Co.,Ltd

INGKE can provide 3D model for engineers' design

Our service:

 1).Free sample is available!

 2).OEM & ODM orders are welcomed.

 3).We offer after-sale service for 8 years.

Our Advantage:

 1).High-quality，OEM factory for RJ45 Connector more than 10 years.

 2).Cost reduction, lead time within 1 week, FREE samples.

3).After sales services 24*7 to help you solve any kind of problems
