REOO Full Automatic Solar Panel Laminating Machines for Solar Module

Name: REOO Full Automatic Solar Panel Laminating Machines for Solar Module
Brand: REOO
SKU: 157274586
Availability: InStock

US$ 55000 - 58000 MOQ: 1 Set

Key Specifications

Brand Name:

REOO

Place of Origin:

China

Model Number:

RO-Q1

Nantong REOO Technology CO.,ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

15 days

Brand Name REOO

Place of Origin China

Model Number RO-Q1

Type Other, solar panel lamiantor

Full automatic laminator

USE : As the equipment of manufacturing solar module limited to laminate glass, EVA , solar cell and back sheet

Specification:

1.Full automatic solar module laminator;

2.PLC + Touch screen control;

3.Energy-saving laminator;

4.Operate,maintain easily.

5.Obtained ISO9001 and CE certification system already.

Technical parameter:

ITEM	SPECIFICATION
Dimension	14600mmx2460mmx1300mm
Laminating area	3600mm x 2200mm
Laminating height	25mm
Total power consumption	75 KW ( AC380V, 60 Hz, or according to customer's nee)
Air source	0.6 - 1.0 MPa.
Operating mode	Manual / Automatic.
Control system	PLC ( Delta)
HIM system	Touch screen ( Delta)
Heating mode	Oil Heating
Temperature control system	PID intelligent temperature
Temperature uniformity in working area	≤ ±1.5 ℃
Temperature control accuracy	≤± 1 ℃
Temperature control range	30℃ - 180 ℃
Pumping rate	70 L/s
Laminating time	2 - 4 mins ( excluding solidification time )
Heating rate	135℃ at room temperature with 50 to 60 minutes
Vacuum rate	200 L / S, the limit vacuum 70 ~ 90 Pa
Vacuum time	90 seconds
Silicone sheet size	3800mm * 2400mm, 5 mm thickness
Lid opening	Straight from the hydraulic
the biggest opening height	200 mm
Total weight	15.8 T
