Help CenterMakita Li-ion Battery Charger 25.2V 2A OTP, OVP,OCP With GS CB UL PSE
Related Products
-
42.5V 4A 4A E-Bike Scooter Car Li-ion Battery Charger With PSEUS$ 29.2 - 30.2MOQ: 100 Pieces -
8.4V 5A 6A 7A Lithium Battery Charger With UL CUL FCC TUV CE Turn LightUS$ 15 - 16MOQ: 300 Pieces
-
46.2V 2A 3A Lithium Ion Battery Charger With SAA UL GS Certificates for Golf Cart /segay /wheelchairUS$ 21.5 - 22.5MOQ: 100 Pieces
-
Specializing in the Production 37.8V 1A 9S Li-ion Battery Charger for Camera Battery ChargerUS$ 5.5 - 6MOQ: 500 Pieces
-
Smart USB Charger 4.2V 1A 2A 5V 1A 2A 3A UL GS Approved EMC LVDNegotiableMOQ: 500 Pieces
product description
Product Electronics Parameter | ||
Product name |
Makita li-ion battery charger 25.2V OTP, OVP,OCP with GS CB UL PSE | |
Model number |
XSG2522000 | |
AC input |
Input Voltage range: |
90~264Vac |
Reted input voltage: |
100~240Vac |
|
InputFrequency Range: |
47~62hz |
|
Input current max: |
1.3A |
|
Inrush current: |
35A Max/240V |
|
Efficiency: |
>89% |
|
No load Input power |
||
Leakage current: |
||
DC output |
Max charging voltage: |
25.2V |
Output voltage tolerance: |
5% |
|
Max charging current: |
0~2A |
|
Ripple and noise: |
||
Charging mode: |
3- stage, CC,CV,trickle charging |
|
Cut off current when charged full |
Optional |
|
LED indicator |
Charging: Red, Charged full: Green |
|
Charging current when charged full |
||
Protection |
Over current protection |
PASS |
Over voltage protection | ||
Short circuit protection | ||
Over Temp protection | ||
Anti-flow protection | ||
Environment |
Operating Temp: |
0℃~+45℃ |
Storage Temp: |
-30℃~+70℃ |
|
Relative Humidity: |
10%~90% |
|
Vibration and shock |
Meet MIL-STD-810D |
|
Safety |
Safety standard |
EN60950,EN61558,EN60335 |
EMC/EMI |
Meet FCC CLASS B,EN55022 CLASS B. |
|
EMS |
EN61000-4-2 |
|
EN61000-4-3 | ||
EN61000-4-4 | ||
EN61000-4-5 | ||
A Harmonic source |
Pass |
|
HI-pot: Primary to Secondary |
3KVAC,5mA,60s |
|
Drop Test |
As per UL regulation |
|
Burning test |
100%,4-5 hours |
|
Life |
MTBF |
50000 hours |
Warranty |
3 years |
|
model list
| Part No | AC INPUT(V) | Power rate | Charging voltage | Charing current |
| W | V | mA | ||
| XSG2520300 | 100~240 | 7.6 | 25.2 | 300 |
| XSG2520400 | 100~240 | 10.1 | 25.2 | 400 |
| XSG2520500 | 100~240 | 12.6 | 25.2 | 500 |
| XSG2520600 | 100~240 | 15.1 | 25.2 | 600 |
| XSG2520700 | 100~240 | 17.6 | 25.2 | 700 |
| XSG2520800 | 100~240 | 20.2 | 25.2 | 800 |
| XSG2520900 | 100~240 | 22.7 | 25.2 | 900 |
| XSG2521000 | 100~240 | 25.2 | 25.2 | 1000 |
| XSG2521250 | 100~240 | 31.5 | 25.2 | 1250 |
| XSG2521500 | 100~240 | 37.8 | 25.2 | 1500 |
| XSG2522000 | 100~240 | 50.4 | 25.2 | 2000 |
| XSG2522500 | 100~240 | 63.0 | 25.2 | 2500 |
| XSG2523000 | 100~240 | 75.6 | 25.2 | 3000 |
| XSG2523500 | 100~240 | 88.2 | 25.2 | 3500 |
| XSG2524000 | 100~240 | 100.8 | 25.2 | 4000 |
| XSG2524500 | 100~240 | 113.4 | 25.2 | 4500 |
| XSG2525000 | 100~240 | 126.0 | 25.2 | 5000 |
| XSG2525500 | 100-240 | 138.6 | 25.2 | 5500 |
| XSG2526000 | 100~240 | 151.2 | 25.2 | 6000 |
| XSG2526500 | 100~240 | 163.8 | 25.2 | 6500 |
| XSG2527000 | 100~240 | 176.4 | 25.2 | 7000 |
| XSG2527500 | 100~240 | 189.0 | 25.2 | 7500 |
| XSG2528000 | 100~240 | 201.6 | 25.2 | 8000 |
DC connecter
Certificates
