Home > Products > New product > A4 A3 F4 copy paper sheeting and wrapping machine
A4 A3 F4 copy paper sheeting and wrapping machine
- T/T L/C D/P D/A
- 7 days
You May Like
-
A4 A3 F4 letter legal copy paper sheeter with packing machine
-
A4 cut-size sheeter with A4 wrapping machine
-
A4 A3 F4 letter legal copy paper sheeting and wrapping machine
-
A4 A3 F4 photocopier paper sheeting and A4 paper wrapping machine
-
A4 A3 F4 copy paper cutting machine and wrapping machine
-
A4 cut-size sheeter with wrapping machine
Product Description
A4 /A3 cut size sheeter with automatic wrapping machine for copy paper
A4 Size Paper Cutting Machine (CHM-A4 Paper Cutting Machine)
This series of machine is used to cutting Big paper roll into A4, A3, B5 and 8.5*11 inch sizes, We also can design according to customers requirement, such as legal size, letter size etc..
Model: CHM-A4-4
MAIN SPECIFICATIONS:
Paper Width: Gross width 900mm, net width 840mm
Cutting numbers: 4 cutting-A4 210mm (width)
Diameter of: Paper roll: Max. 1200mm. Min. 600mm
Diameter of: Paper core: 3 or 6 inches or depend on the demand of clients
Paper weight: 60-100gsm
Sheet length: 297mm
Ream amount: 500 sheets. Height: Max.62mm
Max. Speed of production: 120m/min(depend on different paper)
Max. Numbers of cutting: 404cutting/min
Output of the ream: 3.2 times/min
Load of cutting: 400gsm
Cutting accuracy: about 0. 2mm
Cutting requirement: constant speed, no break in reel, cutting all paper one time , eligible paper.
Drive: AC frequency conversion and step-less
Main power supply: 3*380V AC, 50HZ
Voltage: 220V AC/ 24V DC
Power: 32KW
Compressing air consumption: 300NL/min
Air pressure: 6 bar
Edge cutting: 2*10mm
optional parts:
Auto wrapping system
Contact: Miss Amy
Mobile: 0086 158 8968 1847
Cheungkong Machinery company limited
email: rollpapercutter@gmail.com
AC servo precision high speed sheet cutter
CHM-1400/1700/1900
This series of machine is used to cut the paper roll into paper sheets. It adopts advanced technology of British and it is driven by AC servo motors, the high cutting speed reaches 300 cuts /min. And it can cut 8 paper rolls at one time. It is also equipped with automatic deflection rectify and antistatic device. The paper feeding and delivering units are automatic with the hydraulic system. The human and machine interface system could make operation become much easy and more convenient.
Model: CHM-1400/1700/1900
MAIN SPECIFICATIONS:
weight of paper: 60-550gsm
Cutting accuracy: 0. 5mm tolerance allowed
Max. Cutting speed: 300sheets/min, operation speed depends on cut length, paper quality, paper grade&grammage.
Max. Cutting meter speed: 300m/min
Cutting length range: 450-1450mm
Max. Diameter of reel: 1800mm
Sheet stack height: 1300mm
Max. Width of cutting paper: 1400mm/1700mm/1900mm
MAIN WORK SECTIONS:
Cutting section:
1. Computer operation interface, easy to operate.
2. High precision special alloy steel knife
3. Cutting accuracy is 0. 5mm tolerance
Paper feeding section:
1. Double limbs oil pressure shaftless paper rack
2. Auto tension control system
3. Auto paper edge guiding system
Electric control section:
1. PLC control system
2. AC servo driving motor
3. High precision encoder&cutting
4. Long endurance
Slitting knife:
1. Three sets of slitting knives
2. Used for trimming and middle slitting
Paper conveyer system
1. The number of overlapping sheets can be adjusted by this section.
2. The single sheet outlet can be adjusted.
Contact: Miss Amy
Mobile: 0086 158 8968 1847
email: rollpapercutter@gmail.com
Cheungkong Machinery company limited
