Eddy current separator for metal and plastic

Eddy current separator for metal and plastic

1. Working principle :

When the machine running ,it will produce high frequency alternating magnetic field on magnetic roller ;If the conductive nonferrous metal go though the magentic field ,it will produce induced current and this induced current will produce magnetic field oppsite with original magnetic field ,then the nonferrous metal will fly ahead according this transporting direction by repulsive force of the magnetic field ,hence ,nonferrous metal is separated from other non-metal material .Main standard : ratio of metarial's conductively and material's density;material with high ratio is more easy to be separated than material with low ratio ;

2.Application of eddy current separator :

Eddy current separator is mainly used to recycle copper ,aluinum and other non-ferrous metals from domestic garbage,industrial waste ,electric waste ,glass waste ,bottom ash of boiler ,automobile scraps ,etc . it can be widely used in garbage processing ,used electric equipment recycling and non-ferrous metals process field ,like :

1. electronics waste disposal (electrical household appliances dismantling line ,refrigerator dismantling line ,computer dismantling line ,etc .)


2. Separation of aluminum cans and ferrous metals ;

3. Separate non-ferrous metals from the bottom ash of boiler;

4. Separate aluminum or copper block from the sections of abandoned cars ;

5. Separate non-ferrous metals from the glass scrap ;

6. Separate non-ferrous metal inpurities in some production lines ;

7. Separate non-ferrous metals from recycled plastic doors and windows ;

8. Separate non-ferrous metals from the wood .

3.Composition :

Eddy current separator is composited with main boy of separator and electric controlling cabinet .Main body includes separating assembly ,motor ,frame and cover etc . Core of separating assembly includes permanent magnet rollers ,transporting system (includes transporting belt ,driving roller and reducer )

4.Features :

It has a good seprating results for multiple non-ferrous metal ,strong adaptability,reliable strucure ,strong repulsion with high separating efficiency ;
