YBBP Series Explosion Proof Variable Frequency Adjustable Speed Three-Phase Asychronous Motors
- 1000 Set / Sets per Month
- Shanghai
- T/T
- 10 days
Product Details
Brand Name: | Nanyangfangbao | Place of Origin: | China | Model Number: | YBBP Series Explosion Proof Variable Frequency Adjustable Speed Three-Phase Asychronous Motors |
Product Description
Overview of YBBP Frequency Control and Explosion Proof Motor
YBBP series explosion-proof frequency conversion three-phase asynchronous motor is Nanyang Explosion-proof Motor Co., Ltd. in order to meet the needs of the market, in the introduction of foreign advanced technology and summary of the company for many years experience in the production of variable frequency motor on the basis of the development of a new generation of explosion-proof Frequency control motor, the product used in conjunction with the inverter, you can achieve a wide range of smooth stepless speed, speed range, dynamic response, speed accuracy, low frequency torque, slip compensation, power factor, efficiency and so on There is a great advantage, YBBP frequency control explosion-proof motor to meet the coal, petroleum, chemical and other explosive gas mixture motor explosion-proof performance in line with GB3836.1-2010 "
Explosive atmospheres - Part 1: General requirements "and GB3836.2-2010" Explosive atmospheres Part 2: Provisions for equipment protected by flameproof enclosure "d".
YBBP variable frequency explosion - proof motor parameters
Rated voltage: 380V, 660V, 380V / 660V, 660V / 1140V
Speed range: 5-50HZ for constant torque speed, 50-100HZ constant power speed
Power range: 0.55KW-315KW
Protection class: IP55
Insulation class: F, H
Cooling method: IC416 (forced ventilation)
Application of YBBP frequency explosion - proof motor
This series of motors meet the explosion-proof performance in line with GB3836.1-2010 "Explosive environment Part 1: General requirements" and GB3836.2-2010 "Explosive environment Part 2: Flameproof enclosure" d "protected equipment" Into a flameproof motor, with an explosive gas environment for Zone 1, Zone 2 dangerous places. As a prime mover use, can be widely used in mining, machinery industry, petrochemical industry, power plants and other industrial and mining enterprises, driving a variety of general machinery: such as compressors, pumps, crushers, cutting machine tools, transport machinery and other machinery and equipment.
BS4683 and EN50018 regulations, made of flameproof. Explosion-proof mark for the ExdI, ExdIIAT4, ExdIIBT4, for explosive gas mixture exists in the place.
ExdI is suitable for the presence of methane or coal dust in an explosive mixture of coal mine underground non-mining face environment.
ExdIIAT4 is suitable for use in Class II Class A, where the temperature group is in the presence of explosive gas mixtures for T1, T2, T3 and T4 groups.
ExdIIBT4 is suitable for use in Class B Class B, where the temperature group is in the presence of explosive gas mixtures for T1, T2, T3 and T4 groups.
ExdIICT4 is suitable for use in Class C Class C, temperature groups for T1, T2, T3 and T4 explosive atmospheres
Structural Design of YBBP Frequency Conversion Explosion Proof Motor
Structural design, mainly to consider the non-sinusoidal power supply characteristics of the inverter motor insulation structure, vibration, noise cooling and other aspects of the general attention to the following questions:
1) Insulation class, usually F-class or higher, to strengthen the insulation and line insulation strength, in particular, to consider the ability of insulation impact resistance.
2) on the motor vibration, noise problems, to take full account of the motor components and the overall rigidity, try to improve its natural frequency, in order to avoid resonance with the force wave phenomenon.
3) Cooling: the general use of forced ventilation cooling, the main motor cooling fan using a separate motor drive.
4) to prevent shaft current measures, the capacity of more than 160KW motor bearings should be used insulation measures. Mainly easy to produce magnetic circuit asymmetry, will also produce shaft current, when the other high-frequency components generated by the combination of current, the shaft current will be greatly increased, resulting in bearing damage, so generally take insulation measures.
5) For constant power inverter motors, when the speed exceeds 3000 / min, should use high temperature special grease to compensate for the bearing temperature rise
