YBX3 explosion-proof motor can be used for coal mine (non-mining face) fixed equipment or plant IIB level, due to YBX3 efficient explosion-proof motor must meet the explosion requirements, so a lot of explosion-proof grade, EXDI and EXDII two. There are EXDI used for coal mine non-mining things, the important gas is methane. EXDII is used in workshops where the ignition temperature group is a group of T1 to T4 flammable gases or explosive atmospheres formed by vapor and atmosphere. The temperature group is a drive motor for mechanical equipment in the explosive atmosphere of the T1-T4 group of combustible gases or vapor and air. It is mainly used for coal, oil, natural, petrochemical and chemical industries. Explosion-proof motors are used as the main power equipment, usually used to drive pumps, fans, compressors, conveyors and other transmission machinery. In addition, in the textile, metallurgy, transportation, grain and oil processing, paper, medicine and other departments are also widely used.
YBX3 motor explosion-proof mark on behalf of the meaning: Exd Ⅱ BT4Gb
Ex: explosion-proof electrical signs
d: electrical equipment explosion-proof type (flameproof)
IIB: Class of electrical equipment (Class B Class B)
T4: Applicable temperature group (T4)
Gb: protection level (Gb)
YBX3 Explosion-proof motor model: YBX3-132M2-6F on behalf of the meaning of analysis
Y: Asynchronous motor
B: Flameproof
X: High efficiency and energy saving
3: design serial number, 3 on behalf of the three design
132: Center height of base (132 mm)
M: base length (M means seat)
2: 2 iron long
6: pole number (6 pole)
F: special environmental code (anti-corrosion type)
YBX3 explosion-proof motor installation in line with GB997 "motor structure and installation type code" and IEC34-7 requirements. This series of motors have the following five basic structure types: B3 has a base, no direct installation of the flange, B5 without base, a direct installation of the flange, B35 has a base, a direct installation of the flange. B14-frame without foot, with a small flange; B34- base with a foot, with a small flange cover. This series of motors in the above five basic structure, can be derived from 15 kinds of commonly used structure and installation type see table below:
Frame structure and installation type code (IM)
80 to 112 B3, B5, B6, B7, B8, B14, B34, B35, V1, V3, V5, V6, V15, V18, V35
132 to 160 B3, B5, B6, B7, B8, B35, V1, V3, V5, V6, V15, V35
180 to 280 B3, B5, B35, V1
315 to 355 B3, B35, V1
400 to 450 B3, B35, V1
