Metalized Polypropylene AC Motor Capacitors (CBB65/CBB61/CBB60)

Metalized Polypropylene AC Motor Capacitors (CBB65/CBB61/CBB60)

Product Description

Main Features:
Mall size, small loss, high insulation resistance, reliable electric performance, stable property, strong overload capability.

Product Description:
The capacitor takes heavy-edge metallized Al/Zn PP film or web-like safety film as dielectric. The elements are tight winded by high-velocity winders and canned in aluminum cases. Refined castor oil is adopted as impregnation agent treated in vacuum and high temperature condition. Those make a more reliable performance and longer lifespan for a capacitor. Meanwhile the second generation of mechanical anti-explosion design is selected as blast-proof secure measure for our capacitors. The reliability is more affirmatively enhanced.

CBB65 motor run capacitor has features of small size, light weight, small tangent in waste angle, and good self-concrescence. Applied to the starting and better working of sing-phase motor in 50Hz(60Hz) frequency AC power system.

Technical Specification:
Executive standard: GB36671-997
Technical features:
Reted Voltage: 250~1000VAC
Reted Capacitance. 1~100uf
Rated Frequency 50/60Hz
Climate type: 40/70/21
Capacitance tolerance: +-50%
Loss Tangent: ≤ 0.2%

Application requirements
1. Altitude: <=2000m
2. Residual voltage while loading: Less than 10% of rated voltage
3. Allowed max. Voltage: Less than 1.1 time rated voltage
4. Permissible max. Current: Less than 1.3 time rated current.
