Home > Products > Cold Roll Forming Machine > 0.3 - 0.8 mm Thick Roof Sheet Cold Roll Forming Machine with PLC Computer Control

0.3 - 0.8 mm Thick Roof Sheet Cold Roll Forming Machine with PLC Computer Control

FOB Price

USD $38000 - $38000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TECHWELL		Place of Origin	China
Model Number	TW-RWM

Attribute

Material: PPGI, Galvanized Coil

Main Power: 5.5KW

Diameter of Axis: 75mm

Cutting Blade: Cr12Mov

Forming Station: 10-18

Cutting Method: Hydraulic Cutting

Main Specification

1.	Material thickness	0.3-0.8mm
2.	Material width	depend on customer’s requirement
3.	Decoiler Type	manual or automatical type ( depend on customer’s requirement )
4.	Weight Capacity Of Decoiler	5 Ton
5.	Main Motor Power	5.5 Kw
6.	Hydraulic Motor Power	3 Kw
7.	Forming Station	13-20 ( depend on profile drawing )
8.	Material of Roller	High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
9.	Main Axis Material	High grade 45#, quenched and heat treatment.
10.	Axis Diameter	¢ 75mm
11.	Working Speed	0-15 m/min
12.	Transporting Type	Chain Transmission
13.	Heat Treatment of Cutting Blade	HRC 50-60
14.	Type of Cutting	Hydraulic cutting
15.	Material Of Cutting Blade	C r 12
16.	Heat Treatment of Cutting Blade	HRC 50-60

Working Flow

Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table
