Brand Name
Genicom
Place of Origin
South Korea
Model Number
GUVA-S12SD
Usage
Other, UV Sensor
Theory
Optical Sensor
1.Features
Gallium Nitride Based Material
Schottky-type Photodiode
Photovoltaic Mode Operation
Good Visible Blindness
High Responsivity & Low Dark Current
2.Applications
UV Index Monitoring
UV-A Lamp Monitoring
3.Outline Diagrams and Dimensions
4. Absolute Maximum Ratings
Storage Temperature: -40~90'C
Operating Temperature: -30~85'C
Reverse Voltage: 5V
Forward Current: 1mA
Optical Source Power Range: 0.1u~100m W/cm2
Soldering Temperature: 260'C
5. Characteristics (at 25'C)
Dark Current: 1nA
Temperature Coefficient: 0.08%/'C
Responsivity: 0.14A/W
Spectral Detection Range: 240~370nm
Active area: 0.076mm2
