Help CenterGPS and GSM Combination Antenna LPCG003
Related Products
-
GPS and GSM Combination Antenna LPCG004US$ 1 - 1MOQ: 100 Pieces -
GPS and GSM Combination Antenna LPCG005US$ 1 - 1MOQ: 100 Pieces
-
GPS and GSM Combination Antenna LPCG006US$ 1 - 1MOQ: 100 Pieces
-
WLAN Panel Antenna LPWG002US$ 1 - 1MOQ: 100 Pieces
-
WIFI and GSM Antenna LPWG001US$ 1 - 1MOQ: 100 Pieces
Item
Specifications
GPS Antenna
Dielectric
Antenna
Center Frequency
1575.42±1MHz
Band Width
CF±5MHz
Polarization
RHCP
Gain
5dBic(Zenith)
V.S.W.R
<1.5
Impedance
50OHM
Axial Ratio
3dB(max)
LNA
Gain
28±2dBi
Noise Figure
<1.5
Ex-band Attenuation
12dB CF+50MHz/16dB CF-50MHz
V.S.W.R
<2.0
Supply Voltage
2.2-5V DC
Current Consumption
5-15mA
GSM Antenna
Frequency Range
824-960MHz/1710-2170MHz
V.S.W.R（min）
<2.5
Polarization
Linear
Gain
2dBi
Impedance
50OHM
Mechanical
Cable
RG174
Connector
SMA/MCX/FAKRA or others
Radome Material
ABS
Mounting Method
Magnet
Environmental
Operating Temperature
-40-+85 degree
Relative Humidity
Up to 95%
Vibration
10 to 55Hz with 1.5mm amplitude 2hours
Environmentally Friendly
ROHS Compliant
