0.4 mm - 0.7 mm Thickness Glazed Roof Tile Roll Forming Machine with Hydraulic Station
Technical parameter of glazed roof tile roll forming machine
Item |
Parameter |
|
|
Type |
Color steel sheet |
Thickness |
0.4mm-0.7mm |
|
Yield strength |
230-300 |
|
Forming speed |
5-8m/min |
|
Roller material |
45#steel with chrome coated |
|
Roller driven type |
Chain transmission |
|
Controller |
PLC |
|
Operation |
Touch screen & button |
|
Hydraulic system pressure |
13 |
|
Hydraulic station motor power |
7.5 |
|
Main motor power |
4 |
|
Total power |
11.5 |
|
Total weight |
About 1 ton |
Main components of glazed roof tile roll forming machine
Manual Decoiler |
1 Unit |
Roof Forming Main Machine |
1 Unit |
Control Panel |
1 Unit |
Hydraulic Station |
1 Unit |
Manual out Table |
2 Units |
Working flow
Decoiling----guiding and feeding ----roll forming----pressing----cut to length----run out table
Application
This glazed roof panel used as the roofing of factory, warehouse. It is easy to realize the reliable and safety installation.
Good toughness: with super toughness, Tere is no necessary to do any treatment amontg the nail hole, it is sealing and can prevent leaking water.
Long life: life ≥ 25 years, is an alternative to steel sheet
Corrosion resistance: strong acid, alkali, salt, anti-static, anti-vapor corrosion, etc.
Noise performance: noise performance is good, away from the noise.
The appearance of the shape: color and length can be arbitrarily chosen.
Company introduction
Rishbin was founded in 1999. With more than ten years\' development, now it becomes a leading professional supplier in the field of roll forming machinery industry, and exports its quality production line to the markets all over the world.
we are one of the leading suppliers and manufacturer in china and have been supplying and making roll forming equipment for the metal building construction industry for a long time.
