Certification:CE
High Speed Bemo Roofing Panel Roll Forming Machine Standing Seam Roof Machinery
Main Specifications of bemo roofing panel roll forming machine
| Product Name | Item | Description |
|
Bemo Roofing Panel Roll Forming Machine |
Production Material thickness | 0.3mm-0.8mm, yield strength≤G250MPa |
| Forming speed | 10-15m/min (Not including time of cutting stop) | |
| Shaft diameter | 76mm | |
| Roller material | GCr15 with heat treatment and hard chrome-plated HRC58-62 | |
| Shaft material | High-quality steel 45 quenched and tempered after finishing treatment | |
| Number of stations | 18stations | |
| Main motor power | 7.5 kw | |
| Power of hydraulic station | 3.0KW | |
| Electronic controlling system | Full-frequency PLC controlling system | |
| Material of cutting blade | Cr12 quenched | |
| Cutting | Cutting after forming with hydraulic driving | |
| Machine dimension(mm) | 8000×1400×1300 |
Structure of bemo roofing panel roll forming machine
This Bemo roof machine consists of 5 tons manually decoiler, chain driven transmission device, forming machine, hydraulic cutting device, computerized control cabinet and stacker.
Working process of bemo roofing panel roll forming machine
Coiler loading → feeding-in with guiding (metal sheet is guided into the first forming station) →rolling & forming → cutting after forming→ stacker running out
Components of bemo roofing panel roll forming machine
|
No. |
Composition of machine |
Quantity |
|
1 |
Roll forming main machine |
1 unit |
|
2 |
Manual decoiler |
1 unit |
|
3 |
Cutting system |
1 unit |
|
4 |
Control panel |
1 unit |
|
5 |
Manual out table |
2 units |
Reference photo
Production line sketch
Competitive advantage
1. Automatic roll forming machine
2. High quality
3. Factory direct price
Applications
Standing seam foof panel; Standing seam roof sheet; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; metal roof; steel roof; metal roof wall panel; steel roof wall panel;
Company Introduction
Rishbin was founded in 1999. With more than ten years\' development, now it becomes a leading professional supplier in the field of roll forming machinery industry, and exports its quality production
line to the markets all over the world.
We are Specialists in roll forming machines for manufacture the production of building construction, such as metal roofing and wall, various trapezoidal profiles can be custom manufactured. We build
complete roll forming lines for roofing & cladding lines.
