Ball Mill Series
This machine is made up of feeding part, discharging part, gyre part, transmission part, and so on.
The hollow axis adopts the cast steel and the lining can be replaced, the rotary big gear is processed from cast rolling gear, the barrel body ID wearable well and bears wearable scale board. This machine runs steadily and works reliably.
Brief introduction
Ball mill is an efficient for grinding many materials into fine power. The ball mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc. There are two ways of grinding the dry process and the wet process. It can be individual into tabular type and flowing type according to different forms of discharging material.
This machine is made up of feeding part, discharging part, gyre part, transmission part, and so on.
The hollow axis adopts the cast steel and the lining can be replaced, the rotary big gear is processed from cast rolling gear, the barrel body ID wearable well and bears wearable scale board. This machine runs steadily and works reliably.
Brief introduction
Ball mill is an efficient for grinding many materials into fine power. The ball mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc. There are two ways of grinding the dry process and the wet process. It can be individual into tabular type and flowing type according to different forms of discharging material.
|
Model |
Rev.of Barrel (rpm) |
Ball Lead(mm) |
Feed Size (mm) |
Finished Size(mm) |
Capacity(t/h) |
Power(kw) |
Weight (t) |
|
900*1800 |
38 |
1.5 |
<=25 |
0.075-0.89 |
0.65 |
18.5 |
3.6 |
|
900*3000 |
38 |
2.7 |
<=25 |
0.075-0.89 |
1.1-3.5 |
22 |
4.6 |
|
1200*2400 |
32 |
3.8 |
<=25 |
0.075-0.6 |
1.5-4.8 |
45 |
12.5 |
|
1200*3000 |
32 |
5 |
<=25 |
0.074-0.4 |
1.6-5 |
45 |
12.8 |
|
1200*4500 |
32 |
7 |
<=25 |
0.074-0.4 |
1.6-5.8 |
55 |
13.8 |
|
1500*3000 |
27 |
8 |
<=25 |
0.074-0.4 |
2-5 |
90 |
17 |
|
1500*4500 |
27 |
14 |
<=25 |
0.074-0.4 |
3-6 |
110 |
21 |
