Sand Washer 2LSX/LSX/XSD
1.Low crushing ratio
2.Low operation cost
3.Uniform partical size
4.Reducing cycle load and sealed by grease
Brief Introduction
This product is mainly used for sand factory, electric pole factory, worksite of building concrete dam to wash, classifying and de-watering various sands. This sand washer adopt inclination of 15°, under the water tub , three weir plates form the sediment pool. The screw head is immersed in this pool, and the screw in driven by electric motor through reducer rotating continuously, and then the fresh water is feeding from porous plate at the bottom of sediment pool, this machine are three functions of washing, de-watering ,and classifying.
|
Model |
Helix diameter (mm) |
Length of tub (mm) |
Selected size (mm) |
Capacity (t/h) |
Speed of helix(r/min) |
Electric motor power(kw) |
Water consumption(t/h) |
Weight(t) |
Overall dimensions (mm) |
|
LSX915 |
915 |
7585 |
≤10 |
100 |
21 |
11 |
10-80 |
3.48 |
8500*2950*1930 |
|
2LSX915 |
915 |
7585 |
≤10 |
200 |
21 |
2*11 |
20-160 |
5.2 |
8420*3765*2030 |
|
LSX1115 |
1115 |
9782 |
≤10 |
175 |
17 |
15 |
20-150 |
10.18 |
10970*3954*4720 |
|
2LSX1115 |
1115 |
9782 |
≤10 |
350 |
17 |
2*15 |
40-300 |
17.94 |
10970*5250*4720 |
|
XSD2610 |
2600 |
3220 |
≤10 |
50 |
0.8 |
5.5 |
4-4.5 |
2.7 |
3220*2125*2670 |
|
XSD3016 |
3000 |
3810 |
≤10 |
80 |
0.8 |
7.5 |
16.30 |
3.2 |
3400*2615*2800 |
