Shenyang Heavy Mining Equipment Co., Ltd.
Shenyang Heavymining equipment co., PYT spring cone crusher is widely used inmining, building materials, metallurgy and other industries, canbe for a variety of metal ores, granite, limestone,pebbles, sand and other medium and moderate hardnessof materials, fine crushing.
The main structure andworking principle of PYT spring cone crusher:
PYT spring conecrusher is mainly composed of a machine frame, a fixedcone assembly, movable cone assembly, springmechanism, bowl shaped shaft frame and transmissionparts. The auxiliary part, the electrical system, oillubrication system, and the hydraulic cavityclearing system.
The work, by the motorthrough the belt, a big belt wheel, the driveshaft, pinion, bevel gear drives the eccentric sleeve torotate, crushing cone axis of the eccentricsleeve of forced vibration under rotating, the broken wallsurface and near surface and sometimes from rollingmortar wall, from the material composition inthe ring fixed cone of cone and the crushingcavity is constantly under attack, extrusion andbending and crushing. After several times of extrusion, impactand bending, the material crushing to therequired size, the lower discharge.
Product advantage:
1, squareshank bolt, impact resistance, wearresistance. Splicing structure, handling, installation isconvenient.
2 novel, hammer, impactforce. Compact structure, machine rigidity.
3, feed, high crushingchamber, to meet the material hardness, block degree, lesspowder products.
4, impact, collision attack, (stone stone crushing function), high productionefficiency, small mechanical wear, the remarkable comprehensivebenefit.
5, the size of thegrid can be adjusted, controllable granularity, grainshape good.
