stainless steel wire mesh
US$ 1 - 20
/ Piece
1000 Pieces(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | xinmengda | Place of Origin | China | |
| Model Number | wire mesh |
Product Description
Major wire materials for stainless steel wire mesh is stainless steel 302, 304, 304L, 316, 316L, 2520, 2080; mesh count of square opening stainless steel wire mesh normally ranges from 40mesh to 400mesh; mesh count per inch of Dutch woven wire cloth is from 10mesh/64mesh to 400mesh/2800mesh (Filter Wire Cloth Gauge 40# to 1600#) at a width of 1.5m to 8m. For more information of our Dutch wire cloth, please refer to the link on the left.
|
Stainless Steel Woven Wire Mesh
|
||
|
Mesh/Inch
|
Wire Gauge SWG
|
Aperture mm
|
|
40meshx40mesh
|
36
|
0.44
|
|
50meshx50mesh
|
38
|
0.36
|
|
60meshx60mesh
|
40
|
0.30
|
|
80meshx80mesh
|
42
|
0.21
|
|
100meshx100mesh
|
44
|
0.17
|
|
120meshx120mesh
|
44
|
0.13
|
|
150meshx150mesh
|
46
|
0.108
|
|
160meshx160mesh
|
46
|
0.097
|
|
180meshx180mesh
|
47
|
0.09
|
|
200meshx200mesh
|
47
|
0.077
|
|
250meshx250mesh
|
48
|
0.061
|
|
270meshx270mesh
|
48
|
0.058
|
|
300meshx300mesh
|
49
|
0.054
|
|
325meshx325mesh
|
49
|
0.051
|
|
350meshx350mesh
|
49
|
0.042
|
|
400meshx400mesh
|
50
|
0.0385
|
|
Width: 0.6m-8.5m
|
||
|
Stainless Steel Woven Wire Mesh
|
||
|
Mesh/Inch
|
Wire Gauge SWG
|
Aperture mm
|
|
40meshx40mesh
|
36
|
0.44
|
|
50meshx50mesh
|
38
|
0.36
|
|
60meshx60mesh
|
40
|
0.30
|
|
80meshx80mesh
|
42
|
0.21
|
|
100meshx100mesh
|
44
|
0.17
|
|
120meshx120mesh
|
44
|
0.13
|
|
150meshx150mesh
|
46
|
0.108
|
|
160meshx160mesh
|
46
|
0.097
|
|
180meshx180mesh
|
47
|
0.09
|
|
200meshx200mesh
|
47
|
0.077
|
|
250meshx250mesh
|
48
|
0.061
|
|
270meshx270mesh
|
48
|
0.058
|
|
300meshx300mesh
|
49
|
0.054
|
|
325meshx325mesh
|
49
|
0.051
|
|
350meshx350mesh
|
49
|
0.042
|
|
400meshx400mesh
|
50
|
0.0385
|
|
Width: 0.6m-8.5m
|
||
We hope you kindly enquiry,if you want to get the quotation,please offer the specifications.
thanks!
Hebei Anping Xin Mengda Wire Mesh Co.,Ltd.
