Gr 1 Gr 2 Gr 3 Seamless Titanium Tube With 18000mm Length as per ASTM B338
- 0 Metric Ton / Metric Tons per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Gr7 , Gr9 , GR12 Welded Titanium Tube For Condenser With 355.6mm OD
-
Grade 1 Welded Titanium Tube 0.3mm - 20mm WT , Medical Titanium Pipe
-
Pure Gr5 Welding Titanium Pipe Corrosion Resistance With ASTM SB338 GB/T
-
polished seamless titanium pipe with OD279,355mm
-
St45 St37 E235 E355 Galvanized Steel Tube
-
JIS G3473 DIN2391 Precision Hydraulic Cylinder Piping , Cold-Drawn Round Steel Tubes
Product Details
| Brand Name | HHT | Place of Origin | China | |
Product Description
Certification:EN10204 3.1
Gr 1 Gr 2 Gr 3 Seamless Titanium Tube With 18000mm Length as per ASTM B338
Quick details of Titanium tube:
|
Product Name |
Seamless Titanium and Titanium Alloy Tubes & Pipes |
|
Specification |
ASTM B338/B861 or ASME SB338/SB861 |
|
Material Grade |
Gr 1,Gr 2,Gr 3,Gr 5,Gr 7,Gr 9,Gr 11,Gr 12, etc |
|
Dimension range |
OD 3.0--350.0mm,WT 0.3 to 33.3mm,Length18,000mm |
|
Application |
Heat Exchanger, Condenser, Chemical Processing, Automotive Exhaust, Bicycles, Marine. |
Welding titanium tube:
|
Product Name |
Welded Titanium and Titanium Alloy Pipes |
|
Specification |
ASTM B337/B862 or ASME SB337/SB862 |
|
Material Grade |
Gr 1,Gr 2,Gr 3,Gr 5,Gr 7,Gr 9,Gr 11,Gr 12, etc |
|
Dimension Range |
OD 88.9 to 965mm,WT 1.65 to 12.7mm,Length10,000mm |
|
Application |
Heat Exchanger, Chemical Processing, Automotive Exhaust, Bicycles. |
Description:
ASTM B337,ASTM B338.B861/B862 OD:2.0-350mm WT:0.3-35mm Length: <18000mm Gr1, Gr2, Gr3, Gr5,Gr7, Gr9, Gr12, Gr17
1.Standards: ASTM B338/ASME SB338 /ASTM B337/ASME SB337 /ASTM B861/ASTM B862 GB/T 3624,GB/T 3625
2.Material:Gr1, Gr2, Gr3, Gr5,Gr7, Gr9, Gr12,
3.OD:2.0-350mm; WT: 0.3—33mm; Length: ≤18000mm
4.Packing:Seaworthy wooden case or according to customer\'s request
5. Annual Export Quantity: 500T/year
6.Quality Assurance ----According to globally recognized standards, such as ASTM, AMS, ASME,JIS,MIL...
-----Chemical composition, Mechanical properties, are strictly controlled, All of the products are detected by ultrasonic inspection,making sure that no defects inside the products. Ensuring our clients get the best products.
-----ISO Quality Management System
----- The Third Party Quality Test Certificate, such as SGS
|
N |
C |
H |
Fe |
O |
Al |
V |
Pa |
Mo |
Ni |
Ti |
|
|
Gr 1 |
0.03 |
0.08 |
0.015 |
0.20 |
0.18 |
/ |
/ |
/ |
/ |
/ |
bal |
|
Gr 2 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
/ |
/ |
bal |
|
Gr 5 |
0.05 |
0.08 |
0.015 |
0.40 |
0.20 |
5.5~6.75 |
3.5~4.5 |
/ |
/ |
/ |
bal |
|
Gr 7 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
0.12~0.25 |
/ |
/ |
bal |
|
Gr 9 |
0.03 |
0.08 |
0.015 |
0.25 |
0.15 |
2.5~3.5 |
2.0~3.0 |
