Home > Products > Die-Casting LED Display > P5.21 3 In 1 RGB Slim Led Display Boards Indoor For Disco , Bar
P5.21 3 In 1 RGB Slim Led Display Boards Indoor For Disco , Bar
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
Product Details
Brand Name: | Newstar-LED | Place of Origin: | China | Model Number: | LS-5 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Brilliant contrast ratio, high resolution/high definition
2. Super light and can be installed by one person
3. Super uniformity and no mosaic
4. Available Product Models: P3.91, P4.46, P5.21, P6.25.
5. Waterproof Level: IP21
6. Brightness(cd/m2)>2000nit
P5.21 3 In 1 RGB Slim Led Display Boards Indoor For Disco , Bar
Description:
1. Supper thin Design
500 x 500 x 83mm per panel.
2. Fast and simple Assembly
No tools needed, one person can install at least 70 cabinets per hour. One person can finish the whole
process alone.
3. Light Weight
One Cabinet only weights 8 KG, 32KG for one square meter.
4. Aluminum Materials
good appearance, anti-corrosiveness . 8 kg/panel,
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,
shopping malls, railways, airports, harbors, etc;
Specifications:
1. Indoor LED Display Technical Parameter
Model No. |
LS5 |
Pixel Pitch |
5.21mm |
Module Size |
250*250mm |
Module Resolution(pixels) |
48*48 |
Panel Size |
500mm×500mm |
Panel Resolution(pixels) |
96×96 |
Pixel Configuration(RGB) |
1R1G1B |
Pixel Density(pixels/m2) |
36864 |
Brightness(cd/m2) |
2000 |
Best Viewing Distance(m) |
6-100 |
Max.Power Consumption(W/m2) |
1350 |
Waterproof Level |
IP21 |
Wavelength |
R 620-625 G 520-525 B 470-475 |
LED SPEC |
2020 |
Viewing Angle |
140°(H)/60°(V) |
Operating Temperature |
–20~50°C |
Video Frame Rate(Hz) |
≥60HZ |
Display Refresh Rate(Hz) |
≥300HZ |
Grey Level(colors) |
16.7million |
MTBF |
≥50000 hours |
Lifespan |
≥100000Hours |
Working Voltage |
220V±15% OR 110V±15% |
Drive Mode |
Constant 1/10 |
Graphics Card |
DVI Graphics card |
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
Control System |
LINSN |
Software |
LED studio 10.0 |
Installation |
Wall mount, hung and stand structure |
2. Indoor LED Display Module
Dimensions (w x h) |
250mmx250mm |
Resolution (w x h) |
48 x 48 |
Pixel pitch |
5.21mm |
