P5.33 RGB Die-Casting LED Display , IP21 SMD 3 In 1 LED Display Board
Quick Detail:
1. Brilliant contrast ratio, high resolution/high definition
2. Super light and can be installed by one person
3. Super uniformity and no mosaic
4. Available product model: P3.84, P4, P4.8, P5.33, P6.
5. Waterproof Level: IP21
6. Brightness(cd/m2)>2000nit
Description:
1. Supper thin Design
576 x 576 x 83mm per panel.
2. Fast and simple Assembly
No tools needed, one person can install at least 70 cabinets per hour. One person can finish the whole
process alone.
3. Light Weight
One cabinet only weights 9 KG, 34KG for one square meter.
4. Aluminum Die casting Materials
good appearance, anti-corrosiveness . 9 kg/panel,
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as
banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,
shopping malls, railways, airports, harbors, etc;
Specifications:
1. Indoor LED Display Technical Parameter
|
Model No. |
LS-5 |
|
Pixel Pitch |
5.33mm |
|
Module Size |
288*288mm |
|
Module Resolution(pixels) |
54*54 |
|
Panel Size |
576mm×576mm |
|
Panel Resolution(pixels) |
108×108 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(pixels/m2) |
35,200 |
|
Brightness(cd/m2) |
2,000 |
|
Best Viewing Distance(m) |
5-100 |
|
Max.Power Consumption(W/m2) |
900 |
|
Waterproof Level |
IP21 |
|
Wavelength |
R 620-625 G 520-525 B 470-475 |
|
LED SPEC |
3528 |
|
Viewing Angle |
140°(H)/140°(V) |
|
Operating Temperature |
–40~60°C |
|
Video Frame Rate(Hz) |
≥60HZ |
|
Display Refresh Rate(Hz) |
≥300HZ |
|
Grey Level(colors) |
16.7million |
|
MTBF |
≥50,000 hours |
|
Lifespan |
≥100,000Hours |
|
Working Voltage |
220V±15% OR 110V±15% |
|
Drive Mode |
Constant 1/9 |
|
Graphics Card |
DVI Graphics card |
|
Video Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
|
Control System |
LINSN |
|
Software |
LED studio 10.0 |
|
Installation |
Wall mount, hung and stand structure |
2. Indoor LED Display Module
|
Dimensions (w x h) |
288mmx288mm |
Resolution (w x h) |
54 x 54 |
|
Pixel pitch |
5.33mm |
Pixel Density |
35,200/㎡ |
|
Pixel Configuration |
1R1G1B 3 IN 1 |
LED Type |
3528 LED |
3. Indoor LED Display Cabinet
|
Dimensions(w x h x d)(mm) |
576x576x83 |
Module Quantity |
