P4.46 3 In 1 Die-Casting LED Display Indoor For Railways , Airports

Name: P4.46 3 In 1 Die-Casting LED Display Indoor For Railways , Airports
Brand: Newstar-LED
SKU: 149626578
Availability: InStock

Newstar Optoelectronics

US$ $1 - $1 MOQ: 1 Pole

Key Specifications

Brand Name:

Newstar-LED

Place of Origin:

China

Model Number:

LS-4

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name Newstar-LED

Place of Origin China

Model Number LS-4

Delivery Time:8-25days after received the payment
Certification:CE, RoHS, UL, FCC, ISO

Quick Detail:

1. Super uniformity and without mosaic

2. Perfect contrast ratio, high resolution/high definition

3. Available Item: P3.91mm, P4.46mm, P5.2mm, P6.25mm.

4. Light weight and can be installed by one person

5. One Cabinet only weights 8.5KG

6. Cabinet material: Aluminum

P4.46 3 In 1 Die-Casting LED Display Indoor For Railways , Airports

Description:

1. Slim Design

One cabinet size is 500 x 500 x 83mm

2. Fast Assembly

One person can install at least 70 cabinets per hour without tools.

3. Light Weight

One Cabinet only weights 8.5KG, 34KG for one square meter.

Applications:

Commercial advertising, mobile media, night club, entertainment events, business establishments, such as

banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio,

shopping malls, railways, airports, harbors, etc;

Specifications:

1. Indoor LED Display Technical Parameter

Model No.	LS4
Pixel Pitch	4.46mm
Module Size	250*250mm
Module Resolution(pixels)	56*56
Panel Size	500mm×500mm
Panel Resolution(pixels)	112×112
Pixel Configuration(RGB)	1R1G1B
Pixel Density(pixels/m2)	50176
Brightness(cdm2)	2000
Best Viewing Distance(m)	6-100
Max.Power Consumption(W/m2)	1350
Waterproof Level	IP21
wavelength	R 620-625 G 520-525 B 470-475
LED SPEC	2020
Viewing Angle	140°(H)/60°(V)
Operating Temperature	–20~50°C
Video Frame Rate(Hz)	≥60HZ
Display Refresh Rate(Hz)	≥300HZ
Grey Level(colors)	16.7million
MTBF	≥50000 hours
Lifespan	≥100000Hours
Working Voltage	220V±15% OR 110V±15%
Drive Mode	Constant 1/10
Graphics Card	DVI Graphics card
Video Signal	RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System	LINSN
Software	LED studio 10.0
Installation	Wall mount, hung and stand structure
