Help Center2410 Fuse-LED Lamp Fuse
Related Products
Specifications
>P/N:SMD 2410 fuse>Ir:0.5A-20A
>Ur:250Vac/125Vdc
>Approvals:UL PSE TUV CQC
>Blow:fast-acting
Features:
>Fast acting at 200% overload current level
>Excellent inrush current withstanding capability
>Fiberglass enforced epoxy fuse body
>Copper or copper alloy composite fuse link
>Copper termination with nickel and tin plating
>Halogen free, RoHS compliant and 100% lead-free
>Operating temperature range: -55°C to +125°C (with de-rating)
Agency Approval:
>Recognized Under the Components Program of Underwriters
Laboratories. File Number: E232989
>PSE Certificate No: NBK180711-JP13710
>TUV File Number: 50209083
>CQC No.: CQC11012065955
Typical Applications:
>Power Supply, e.g. DC/DC converters, DC/AC inverters, Backlight
drivers , etc.
>Consumer Electronics, e.g. LCD TVs, PDP, DVDs, PCM , etc.
>Communication Technology, e.g. Telecom systems, Networking,
Modems, Routers, Changers, Base stations , etc.
>Office Automation Electronics
>IT Products, e.g. LCD monitors, Notebooks, PC servers, etc.
1. Measured at ≤ 10% rated current and 25ºC ambient
2. Melting I2t at 0.001 seconds pre-arcing time
1. We can deliver all over the world by DHL, UPS, FedEx, TNT and EMS. The packaging is very safe and strong. Please notify me if you have any special needs.
2. It will take around 3-5 days to reach your hands after production.
We provide all-round services from the inquiry period to the after-sale service period.
Our department would take it as the priority to produce for your order. Short-lead time is guaranteed.
The airway bill number will be offerred to to you for checking once available.
You can return the goods free of charge if any problems were found in our products.
Warranty period is 2 years.
Please contact me for more. Call me Tyler.
Skype ID: tianruifuse101
