Hydraulic Gantry Moving Cutting Machine/fabric/rubber/leather Cutting

US$ 4,500 - 4,500 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

GSB

Model Number:

GSB-400

Jiangsu Southocean Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name GSB

Model Number GSB-400

After-sales Service Provided No overseas service provided

Hydraulic Gantry Moving Cutting Machine

1.specially designed oil way system
2.different sizes of die cutters
3.direct factory
4.ISO9001&CE certification

Product Name	Origin	Brand
Intermediate Relay	France	Schneider
Cocontactor	France	Schneider
Sealing Element	USA	Parker
Oil Pump	Sino-Japanese joint venture	LIAONING TECK
Oil Tube	Germany	QC610
Oil Cylinder	Sino-Japanese joint venture	Pioneer
Solenoid Valve	Taiwan	NORTHMAN
Pilot Switch	Taiwan	Tend
Motor	Shanghai	DEDDONG
Mechanical capacity: The cutting press is applicabke for blanking with molding cutters single-layer or multi-layernon-metallicmaterials such as leather, rubber, plastics, cardboard, textile, chemical fibers, non-woven fabrics etc. 1. The cutters move laterally and can be easliy controlled by manual button and automatic displacement switch. 2. Gantry construction provides favorable view during operation. 3. Low pressure setting allows short-cut, accurate regulation on cutting travel. 4. The machine tool could also be fitted with digital control system upon user’s request, which features automatic die allocation and blanking, high accuracy and conservation of material, improving the work efficiency and easing the labor.

Main technical parameters:

Model	GSB-400
Maximum Scissoring Force	40T
Sway Arm Width	50-150mm
Scissoring Speed	0.15m/s
Distance Between Upper and Lower Table	170mm
Press Board ( length×width )	500×500mm
Table Area	1760×520mm
Main Motor Power	2.2kw
Auxillory Motor	0.37kw
