Product Details

Brand Name	HD		Place of Origin	China
Model Number	YE3-B3

Product Description

Delivery Time:15 working days after order
Certification:CE/CCC/ISO9001

2 / 1 Horsepower 200KW / 375KW Low Voltage Electric Motor WITH H80-355 Cast Iron Frame

Description:

YE2 series high-efficiency three phase asynchronous motor is a development based on the YP2 series motor while considering the demand for energy conservation around the world. The mounting, bearings, terminal box, mounting dimensions are as the same as YP2 series. But its average efficiency is 2.55%higher than YP2 series motor.

According to IEC standard and Chinese energy-efficiency standard profoundly,this series reach the internationally general protection level(IP55)and insulation class (F insulation and B temperature rise).Boast several features such as high efficiency, high starting torque, low noise, more reliable structure and well appearance.

Adopt the cooling method of IC411 that is matured in the cooling and heat dissipation.

Our company has passed ISO9001 certification and followed its requirements from ordering, development, fabrication, inspection to sales service strictly.

Ambient
Temperature range:	-15~40℃
Ambient humidity:	90%less than relative humidity
Altitude:	less than 1000m above sea level
Ambient condition:	no causticity gas, no dust, no heavy mental pollution, no flame, no salt crystallization
Supply power:
Voltage variable	±5%
frequency variable	±2% Combine voltage and frequency variable : ±5%
Standard Feature:
Standard	IEC/GB
Efficiency Level	IE3
Phase	Three-phase
Frame Size	H80~355 Cast iron frame
Protect Feature	Totally Enclosed
Output Range	0.75~375KW
Voltage	380V
Frequency	50HZ
Pole	2,4,6
Protection Class	IP55
Insulation	F/B
Mounting	IMB3/IM1001
Cooling	IC411
Duty	S1
Connection	” Y\" type for 3kW and downwards, \"D\" type for 4kW and upwards
Thermometry	Optional
Certification	CCC, CE,ISO9001
Special motors can be designed according to customers\' requirements

Greasing Period

Greasing Type	Frame Size	Poles	Grease Life/Relubrication Interval(Up to CT40℃)
Prelubricated	H80~160	2	20000 h
4,6	40000 h
H180~280	2	20000 h
4,6	40000 h
Regreasing	H315~355	2	30000 h
4,6	60000 h

Rated Power

Motor Type	2 pole /3000 rpm	4 pole /1500 rpm	6pole /1000 rpm
kW	HP	kW	HP	kW	H
