Goods: wall horizontal mounted 3 way Brass Thermostatic Shower Mixer taps with cross handle
Thermostatic Mixer Valve features :
this thermostatic shower valve with 3 handle ,one for thermostatic control handle ,one for on/off handle and one for 3 outlet diverter ,full brass made ,chrome finish ,high flow design ,especially suitable in low water pressure but still keep normal outlet flow rate .The thermostatic mixer valve gives you complete temperature control with a built-in anti-scalding device, so you\'ll never have to worry about a drop in temperature again.will supplies water to either a fixed shower head, a handset, body jets or tub filler.....
Specifications:
|
Weight |
5kg per piece |
|
plate size |
(H x W) 330mmx180mm |
|
Connection thread |
3/4\' female Inlets and Outlets |
|
Cartridge |
Ceramic Disc Technology ,48mm dia cartridge . |
|
work pressure |
0.05Mpa-1Mpa,ideal 0.1-0.5Mpa, |
|
Work temperature |
Pre-set maximum temperature 85C,ideal hot water supply temperature 60-70C ,cold water 5℃-29℃ |
|
temperature adjust |
Thermostatic cartridge with preset temperature stop 38°C and Separate 20-50 C |
|
Safe device |
Automatic anti scald,if cold water supply fail ,hot flow rate will be reduced to virtually shut off |
|
note |
using more functions simultaneously may reduce the water flow to both outlets. |
Working Application:
well work at combine boilers ,gravity fed systems ,unvented mains pressure systems and for shower pumps.
Advantage :
1. Thermostatic control means no more fluctuations between cold and hot water
2. higher flow rates design , can work at low or high water pressure but always keep normal outlet flow rate .
3. made from 62# brass pressure casting made,high density,It’s Green, Clean and Hygiene Products
4. the plates are adjustable by 35mm for easier install ,suitable for any thickness of tile or grout
5. Leak Resistance: Passed the leak tests repeatedly to avoid the leak, even at high pressure up to 2Mpa
6. All components are replaceable without removing the valve ,easy maintenance
7. With non return valves ,never worry scalding or drop in temperature
8. Removable filters to trap debris
9. 1/4 turn on/off cartridge ,easy operation
10. from specialized thermostatic products manufactory ,full experience in thermostatic products more than 15 years
11. we offer full range of shower component ,can be combine to many shower set design
12. 3 year quality guarantee
Product Image
