wall mounted high flow horizontal type 3 way thermostatic shower mixer valve
Description and Advantage :
3 way design ,can supply water to shower head ,massage jet ,hand shower ,bath spout ......
1. Perfect Thermostatic control ,means adjust temperature everytime ,no more fluctuations between cold and hot water
2, in wall mounted , save space
3. made from 62# brass ,pressure casting process,high density,and Green, Clean and Hygiene
4. easy operation,1/4 turn on/off cartridge
5. Laser printed dials,easy discerment
6. higher flow rates design , can work at low or high water pressure but always keep normal outlet flow rate .
7. heavy design ,5kg per piece ,strong and safe
8. easy install , the plates are adjustable by 35mm suitable for any thickness of tile or grout
9. high pressure Leak test and Passed the leak tests repeatedly to avoid the leak
10 easy maintenance,All components are replaceable without removing the valve
11. Automatic anti scald,With non return valves ,never worry scalding or drop in temperature,if cold water supply fail ,hot flow rate will be reduced to virtually shut off
12. Removable filters to trap debris
13. from specialized thermostatic products manufactory ,full experience in thermostatic products more than 15 years
14. we offer full range of shower component ,can be combine to many shower set design
15. 3 year quality guarantee
Specifications:
|
Weight |
5kg per piece |
|
Overall Dimensions |
(H x W) 330mmx180mm |
|
Connection |
3/4\'Inlets and Outlets Compatible with standard plumbing connections |
|
Material |
solid brass ,from 62# brass pressure casting made,high density,It’s Green, Clean and Hygiene Products |
|
Cartridge |
Ceramic Disc Technology ,48mm dia cartridge . |
|
work pressure |
0.05Mpa-1Mpa,ideal 0.1-0.5Mpa,installation reducing valve while exceeding ideal pressure . |
|
Work temperature |
Pre-set maximum temperature 85C,ideal hot water supply temperature 60-70C ,cold water 5℃-29℃ |
|
Preset temperature |
Thermostatic cartridge with preset temperature stop 38°C and Separate controls for temperature outlet range 20-50C |
|
Safe device |
Automatic anti scald,if cold water supply fail ,hot flow rate will be reduced to virtually shut off |
|
Temperature adjust |
Temperature control can be locked in position when setting up the required temperature , you will be able to reach the demand temperature after outlet within 5S,and the outlet fluctuate within +_2C |
|
note |
using more functions simultaneously may reduce the water flow to both outlets. |
Application:
Suitable for combine boilers ,gravity fed systems ,unvented mains pressure systems and for shower pumps.
Use for any bathroom of family ,hotels......
