Home > Industrial Equipment & Components > Environment Protection Device > Waste Treatment Equipment > 6000BPH 500ml Water Bottling Plant Equipment , 18-18-6 Rinser Filler Capper Machine

6000BPH 500ml Water Bottling Plant Equipment , 18-18-6 Rinser Filler Capper Machine

Negotiable MOQ: 1 Metric Ton (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

BJM

Place of Origin:

China

Model Number:

CGF18-18-6

Contact Supplier Request Quote Chat Now

Benjamin Machinery Company

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name BJM

Place of Origin China

Model Number CGF18-18-6

Delivery Time:30 days after deposit and bottle sample received
Certification:ISO9001, CE

6000BPH/500ml Automatic Water Bottle Filling Machine 18-18-6 Rinser Filler Capper Machine

Quick Detail:

Application: Pure water/Mineral water/Drinking water/Non-carbonated waterCapacity: 5,000 to 6,000 bottles per hourWashing Head: 18pcsFilling Head: 18pcsCapping Head: 6pcsSuitable Bottle: 200ml to 1.5LSuitable Cap: Screw cap, Pressing CapBottle Type: PET/PP/PE/HDPE Plastic BottleBottle Shape: Round/Square/Rectangular/Irregular

Specifications:

Application	Mineral water, Purified Water, Still Water…Non-carbonated water
Suitable bottle	PET bottle with size 200ml to 1500ml
Bottle Height	Bottle height. Φ160—φ340mm
Bottle Diameter	Bottle dia.φ50-φ90mm
Suitable cap type	Plastic Screw Cap
Supply Capacity	5,000 to 6,000 bottles per hour(500ml bottle)
Filling style	Mico Low Negative filling type
Filling Temperature	ambient/Room Temperature
Voltage	220/380V(Custom made)
Automatic Grade	Fully Automatic
Driven Type: Electric	Electric
Material:	High quality SUS304 stainless steel
After-sales Service Provided	Engineers available to service machinery overseas

Description:

1, The water filling machine is used in filling mineral water, purified water, still water etc in bottles made of polyester and plastics. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.

2, The washing, filling and capping 3 in 1 job can be finished by one machine automatically, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, and bottle changing is easier.

3, The water filling operation is faster and more stable because the micro gravity filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications.

4, The full line water filling includes: Washing-filling-capping 3 in 1 machine, lamp checker, label shrinking machine, code printer, hot shrink packing machine/carton packing machine and conveyors. It is a full automatic production line.

Competitive Advantage:

1, Water Filling Machine uses neck handling by grippers bottle transmission,2, Fully automatic rinsing, filling and capping by PLC control;3, No bottle no rinsing;4, International brand Electrical components;5, All material contact parts are made of qualified stainless steel, wearable, stable with less malfunction.6, Using starwheel as its drive mechanism, which realize automatically rinsing, filling and capping.

Benjamin Machinery pays great attention to technology, such as beer processing and filling technology, high-viscosity filling technology, glass bottle water filling technology. And we will try our best to satisfy your requirement, your message will be highly appreciated. Welcome to Benjamin Machinery.
