7.5kw Color Steel Sheet Wall / Roof Panel Roll Forming Machine 0.3-0.8mm Thickness

7.5kw Color Steel Sheet Wall / Roof Panel Roll Forming Machine 0.3-0.8mm Thickness thumbnail-1
7.5kw Color Steel Sheet Wall / Roof Panel Roll Forming Machine 0.3-0.8mm Thickness photo-1
US$ 15000$ - 40000$ MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
ZOOY
Place of Origin:
China
Model Number:
ZO-RFL
Contact Supplier Request Quote Chat Now
Wuxi Zooy Machinery Co.,ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name ZOOY
Place of Origin China
Model Number ZO-RFL
Delivery Time:45days after get 30% down payment
Certification:CE

7.5kw Motor Power Roof Panel Roll Forming Machine For Residential roofing & cladding, 0.3 - 0.8mm Thickness Color Steel

Description

Roller Forming Machine -------------1 unit 5 tons decoiler------------------------1 unit PLC Control Panel---------------------1 unit Hydraulic station----------------------1 unit Post-Cutting---------------------------1 unit Motor Power---------------------------1 unit Out-table-----------------------------2 pics Safety Cover-------------------------1 unit

Main Specifications


Coil Material

Thickness

0.3-0.8mm

Coil width

Depend on customer’s requires

Yield Strength

250-550Mpa

Material

PPGI, Color Steel, GI. Aluminium

Decoiler / Uncoiler

Coil Width

Max. 1000mm

I.D

510-610mm

O.D

Max. 1200mm

Capability

Max. 5tons

Decoiler type

Manual / Hydraulic/Automatic

Feeding & guiding

Pinch feeding

1 Units ( 2 Rollers )

guiding

2 Rollers

Cutting device

Cutting motion

Hydraulic Cutting, post-Cutting ( cutting sheet after forming )

Cutting blades

Cr12Mov with heat treatment HRC58-62

Length Measuring

Automatic length measuring by encoder & PLC.

Cutting Tolerance

1.5mm(per 3m)

Roll Forming Machine

Forming Stations

ABOUT 18-20steps



Roller material

45# steel, heat treatment

Diameter of shaft

75mm

Shaft material

High grade 45# steel

Drive type

Driven by Motor,transmission by Chains

Forming speed

0-15m/min

Main power

7.5kw



Electrical control

PLC

PANASONIC Brand or Custom-made

Inverter

YASKAWA Brand or Custom-made

Touch screen

MCGS Brand or Custom-made

Operation type

Touch screen & Button

Hydraulic Station

Hydraulic station

Famous Chinese brand

Hydraulic power

5.5KW

Runout Table

Table type

Simple non-power type

Function

To support the finished panels

 WEIGHT

APRRO 5 TONS


The type pursues board (basis on customer\'s requires to design)


Our Advantage

Stationary style Affordable High Quality Reliable Durable Reasonable Price Good after Service 1 Year Warranty More Than 10Years Experience

.
Warranty: 1 year warranty from date of shipment
Guarantee:
1:Guaranteed against malfunctions due to manufacturing defects for 1 year after date of purchase. Repairs will be made free of charge.
2:Reparis will not be performed free of change even during the guarantee period in the follow circumstances
-  damage occurs due to a natural disaster
-  malfunction occurs due to user error
-  malfunction occurs due to modifications
-  malfunction occurs due to further movement or shipment after installation
3:Air ticket, tra
