Aluminum Sheet Roof Panel Roll Forming Machine with post Cutting 15m/min
- T/T L/C D/P D/A
- 7 days
You May Like
-
High speed Glazed Tile Roll Forming Machine production line With 23 Forming Stations
-
Steel Structure sheet Floor Decking Roll Forming Machine with 11KW Mortor Driven
-
Customized silver Durable Metal Deck Roll Forming Machine with PLC Control System
-
corrugated sheet Metal Deck Roll Forming Machine 22KW with Hydraulic Cutting System
-
Color Steel Corrugated Roofing Wall Panel Roll Forming Machine With PLC Control
-
Galvanized steel sheet Roofing / Floor Deck Roll Forming Machine 15m/min
Product Details
| Brand Name | ZOOY | Place of Origin | China | |
| Model Number | ZO-RT1220 |
Product Description
Certification:CE
0.4-0.8MM Thickness Roof Tile Roll Forming Machine For Galvanized steel, Color Steel, Aluminum Sheet
Composition of machine
|
Roll forming main machine |
1 unit |
|
Roll forming main machine |
1 unit |
|
5T manual de-coiler |
1 unit |
|
Control panel |
1 unit |
|
Hydraulic station |
1 unit |
|
Manual out table |
2 unit |
|
Spare tools |
1 unit |
Main Specifications
|
Coil Material |
Thickness |
0.4-0.8mm |
|
Coil width |
Depend on customer’s requires |
|
|
Yield Strength |
G250Mpa |
|
|
Material |
Galvanized steel sheet |
|
|
Decoiler / Uncoiler |
Coil Width |
Max. 1300mm |
|
I.D |
510-610mm |
|
|
O.D |
Max. 1200mm |
|
|
Capability |
Max. 5 Tons |
|
|
Decoiler type |
Manual / Hydraulic/Automatic |
|
|
Feeding & Leveling |
Pinch feeding |
1 Units ( 2 Rollers ) |
|
Cutting device |
Cutting motion |
Hydraulic Cutting, post-Cutting ( cutting sheet after forming ) |
|
Cutting blades |
Cr12Mov with heat treatment HRC58-62 |
|
|
Length Measuring |
Automatic length measuring by encoder & PLC. |
|
|
Cutting Tolerance |
1.5mm(per 3m) |
|
|
Roll Forming Machine |
Forming Stations |
20 Stations |
|
Rectifying |
1 unit |
|
|
Roller material |
GCr15 steel, heat treatment |
|
|
Diameter of shaft |
80mm |
|
|
Shaft material |
High grade 45# steel |
|
|
Drive type |
Chains |
|
|
Forming speed |
15m/min |
|
|
Main power |
7.5KW |
|
|
Servo motor |
1 Units |
|
|
Driven System |
Driven by Motor |
Transmission by chains |
|
Electrical control |
PLC |
PANASONIC Brand or Custom-made |
|
Inverter |
YASKAWA Brand or Custom-made |
|
|
Touch screen |
MCGS Brand or Custom-made |
|
|
Operation type |
Touch screen & Button |
|
|
Hydraulic Station |
Hydraulic station |
Famous Chinese brand |
|
Hydraulic power |
7.5KW |
|
|
Runout Table |
Table type |
Simple non-power type |
|
Function |
To support the finished panels |
|
|
TOTAL WEIGHT |
APRRO 8 TONS |
Products Photos
Competitive Advantage:
Economical Simple Standard speed High Quality Reliable Durable Reasonable Price Good after Service 1 Year Warranty More Than 10Years Experience.
Guarantee:
1:Guaranteed against malfunctions due to manufacturing defects for 1 year after date of purchase. Repairs will be made free of charge.
2:Reparis will not be performed free of change even d
