Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > Pure Copper Wire 99.99%

Pure Copper Wire 99.99%

Name: Pure Copper Wire 99.99%
Brand: amity
SKU: 149483528
Availability: InStock

Negotiable MOQ: 1 Ton (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Henan, China

Brand Name:

amity

Model Number:

enameled wire

Contact Supplier Request Quote Chat Now

Henan Amity Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO TIANJIN SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Henan, China

Brand Name amity

Model Number enameled wire

Type Insulated

Application Other, transformers

Conductor Material Copper

Conductor Type Solid

Insulation Material Enameled

Specifications

enameled flat copper wire
1.thermal class: 130--240class
2.standards: 60317-16, 60317-16/28
3.section area: 1.6mm2-80mm2

Specifications of enameled flat wire
1 Flat wire thickness:0.80-5.60mm
2 Flat wire width:2.00-16.00mm
3 Width/thickness ratio:1.4<w/t<8.0
4 Type: enamelled copper wire,enamelled aluminum wire
5 Standard:IEC 60317-16,60317-16/28,MW36 60317-29 BS6811 ,MW18 60317-18 ,MW20 60317-47
6 Thermal Class:120°C ,130°C ,155°C, 180°C ,200°C, 300°C
7 Rross section range:2-80mm2
8 Range of insulation thickness:IEC60317-0-2 G1,0.06-0.11mm G2,0.12-0.17mm
9 Enamel base coat:
1)Polyester
2)Modified Polyester
3)Polyester-Imide
4)Polyvinyl fomal Polyimide
10 Heat shock:155°C -300°C

Features of enameled flat wire
1) Excellent bending property
2) High flexibility of the enamel
3) Good resistance to abrasion
4) High mechanical property
5) Higher thermal property
6) Good resistance to refrigerant and freon
7) Suitable for windings that are subjected to constantly high temperature and mechanical stress
8) Good chemical resistance
9) Outstanding mechanical and chemical property

Applications of enameled flat wire
1) 120 degree flat enameled wire for oil-immersed transformer
2) 130,155,180 degree flate enameled wire are widely used in all kinds of magnet coil
3) 200 degree flat enameled wire works constantly in high temperature
4) 240 degree flat enameled wire for magnet coils of aviation,military and marine appication

Detailed informations of enameled flat wire

Parameter	SMB-130	SMGB-155	SMYB-180	SMYB-200	SMCB-120	SMCYB-240
Standars	IEC60317-16 GB/T7095.7	60317-16 GB/T7095.3	60317-28 GB/T7095.4	MW 36 60317-29 BS6811 GB/T7095.6	MW 18 60317-18 GB/T7095.2	MW 20 60317-47 GB/T7095.5
Thermal Class	130°C	155°C	180°C	200°C	120°C	240°C
Enamel Base Coat	Polyester	Modified Polyester	Polyester-Imide	Polyester-Imide	Polyester-formal	Polyimide
Enamel Top Coat				Polyester-Imide
Range of insulation thickness	IEC60317-0-2 G1,0.06-0.11mm G2/0.12-0.17mm
Performance	1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property	1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property 5.Higher thermal property	1.High thermal resistance 2.Suitable for windings that are subjected to constantly high temperature and mechanical stress 3.Good chemical resistance	1.Excellent thermal resistance 2.Suitable for windings that are subjected to constantly high temperature and mechanical stress 3.Good chemical resistance 4.Good resistance to refrigerant and freon	1.Excellent bending property 2.High flexibility of the enamel 3.Good resistance to abrasion 4.High mechanical property	1.Excellent thermal resistance suitable for any electric equipments that are constantly exposed to high working temperature 2.Outstanding mechanical and chemical property 3.Good performance against radiation
Application	1.Dry and oil-immersed 2.Electrical equipment	1.Dry and oil-immersed 2.Electrical equipment	1.Windings of high and low voltage DC/AC motor 2.Magnet coil 3.Dry and oil-immersed transformer	1.Windings of high and low voltage DC/AC motor 2.Magnet coil 3.Dry and oil-immersed transformer 4.Automobile coil 5.Train coil	1.Dry and oil-immersed transformer 2.Electrical equipment	1.Windings with service temperature up to 220°C 2.Motor and generator for aviation and marine application 3.Nuclear industry 4.Windings requiring high reliability
Heat shock	155°C	175°C	200°C	220°C	155°C	300°C
