Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min
Negotiable
/ Piece
1 Piece(Min.Order)
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
High rigidity Spindle of heavy cutting structure CNC Lathe Hydraulic tailstock
-
High precision CNC Lathe Machine Automatic lubricating with feeding motor and leadscrew
-
High rigidity CNC Lathe Machine with 45Integrated / Hollow Hydraulic 3 - jaw chuck
-
Roll Notching Vertical CNC Milling Machines / Tabletop milling machine
-
CNC Roll Notching and Marking Machine for professional deformed steel bar notching
-
Four controlled axes thread slot CNC Milling Machines high - torque 130 AC
Product Details
| Brand Name | Eagle | Place of Origin | China | |
| Model Number | CK6136/500mm/750mm/1000mm |
Product Description
Certification:ISO9001:2000
Hydraulic Pneumatic chuck CNC Lathe Machine 900mm Z axis / 100 ~ 2500r / min
CK6136/500mm/750mm/1000mm CNC Lathe (Heavy-Duty type) processing for Internal or external diameter,face,taper,ARC and threading with high efficiency.Spindle speed changed by frequency and standard tool post is 4-stations.
CK6136 CNC Lathe (Heavy-Duty type)
Features:
| Condition: |
New
|
Place of Origin: |
Anhui,China (Mainland)
|
Brand Name: |
Eagle
|
| Model Number: |
CK6136/500mm/750mm
/1000mm
|
Type: |
Horizontal
|
CNC or Not: |
CNC
|
| Voltage: |
220V,380V
|
Power(KW): |
3KW
|
Dimension(L*W*H): |
1850×1100×1650mm
1900x1100x1650mm
2300x1100x1650mm
|
| Weight: |
1400/1500/1600kgs
|
Certification: |
ISO9001:2000
|
Warranty: |
one year
|
Main parameter and specifications:
| SPECIFICATION | |||
| ITEM | CK6136/500mm | CK6136/750mm | CK6136/1000mm |
| Swing over bed | Φ360mm | Φ360mm | Φ360mm |
| Swing over carriage | Φ150mm | Φ150mm | Φ150mm |
| Taper of spindle | Through hole | Through hole | Through hole |
| Spindle bore | Φ51mm | Φ51mm | Φ51mm |
| Range of speed(variable) | 100~2500r/min | 100~2500r/min | 100~2500r/min |
| Feed motor power(X/Z) | 4N.M/6N.M | 4N.M/6N.M | 4N.M/6N.M |
| X rapid traverse | 6m/min | 6m/min | 6m/min |
| Z rapid traverse | 6m/min | 6m/min | 6m/min |
| Max. travel of X axis | 170mm | 170mm | 170mm |
| Max. travel of Z axis | 400mm | 650mm | 900mm |
| Motor power | 3Kw | 3Kw | 3Kw |
| Tool-post | 4 stations | 4 stations | 4 stations |
| Max.tool size | 16×16mm | 16×16mm | 16×16mm |
| Min input unit | 0.001mm | 0.001mm | 0.001mm |
| repeatability accuracy(X/Y) | 0.016mm | 0.016mm | 0.016mm |
| Barrel travel of tailstock | 130mm | 130mm | 130mm |
| Barrel taper of tailstock | M.T.3 | M.T.3 | M.T.3 |
| Packing size(L×W×H) | 1850×1100×1650mm | 1900×1100×1650mm | 2300×1100×1650mm |
| N/G Weight | 1400kg | 1500 | 1600kg |
| Loading amount | 6pcs/20\' container | 6pcs/21\' container | 5pcs/22\' container |
Standard accessories:
3-jaw chuck and tool post and wrench.
Allen wrench
Electrical tool post(4-station)
Cooling system
Manual lubrication system
Working lamp
GSK CNC controller system.
.
Optional accessories:
1. 6-station tool post.
2. Pneumatic chuck.
3. Hydraulic chuck.
4. Controller system: SIEMENS802S and 802C.
5. Atuo-lubrication system.
6.Bar auto-feeding device(only for model CK6136)
Advantage:
1. Professional make it for years and have a rich experience.
