3 Kw Hydraulic Motor Power Trapezoidal Roofing Sheet Roll Forming Machine TW-RWM
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TECHWELL
Place of Origin:
China
Model Number:
TW-RWM
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Color Steel Trapezoidal Panel Profile Roll Forming Machine With Panasonic PLCNegotiableMOQ: 1 Piece -
1060mm Trapezoidal Roof Sheet Roll Forming Machine With C r 12 Cutting BladeNegotiableMOQ: 1 Piece
-
0.3 - 0.8mm Forming Thickness Trapezoidal Profile Roof Panel Roll Forming MachineNegotiableMOQ: 1
-
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For RoofingNegotiableMOQ: 1 Set
-
Metal Wall Sheet Roll Forming Machine With 13 - 20 Forming StationNegotiableMOQ: 1 Piece
Brand Name
TECHWELL
Place of Origin
China
Model Number
TW-RWM
Delivery Time:55-65 working days
Certification:CE
Certification:CE
3 Kw Hydraulic Motor Power Trapezoidal Roofing Sheet Roll Forming Machine TW-RWM
Main Components of Trapezidal Roofing Sheet Roll Forming Machine
| Decoiler / Uncoiler | 1 Unit |
| Feeding Guide | 1 Unit |
| Trapezoidal Roofing Sheet Roll Forming Machine | 1 Unit |
| Hydraulic Cutting Part | 1 Unit |
| Hydraulic Station | 1 Unit |
| PLC Computer Control Box | 1 Unit |
| Support Tables | 2 Units |
Applications
Trapezoidal roofing sheet, trapezoidal roof panel, trapezoidal sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding...
Maintenance of Trapezoidal Roofing Sheet Roll Forming Machine
Daily maintenance plays an very importance role in extending the operation time and of Trapezoidal roofing sheet roll forming machine and the good quality finished trapezodial roofing. The following points should be part of the machine\'s daily production and usage routine.
Regularly lubricated the outside parts of the trapezoidal roofing sheet roll forming machine, such as the driving chain... Regularly brush the surface of roller, particularly when working outside. If you do not use the trapezoidal roof panel forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine. If the Trapezoidal sheet roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming dampt, especially the PLC electric control board. Make sure the cutting system is lubricated when necessary. Check the Hydraulic station often and the oil quantity of the deceleration machines, add more oil if the oil level is low. Check the electric appliances box and every leads conjuction circumstance of the trapezoidal roof sheet roll forming machine.Reference Specifications of Trapezoidal Roofing Sheet Roll Forming Machine
| Item | Trapezoidal Roofing Sheet Roll Forming Machine | |
| Coil Material | Thickness | 0.3-0.8mm |
| Coil width | Custom-made, 1000mm or 1200mm or 1250mm | |
| Yield Strength | 250-350 Mpa | |
| Material | PPGI, Color Steel, GI. | |
| Decoiler / Uncoiler | Decoiler Type | Manual or Hydraulic or Auto Type |
| Coil Width | Max. 1250mm | |
| I.D | 508-610mm | |
| O.D | Max. 1500mm | |
| Trapezoidal Roofing Sheet Roll FormingMachine | Forming Stations | 16-18 Stations ( Depend on Profiles ) |
| Roller material | 45# steel, surface coated with 0.05mm hard chrome | |
| Diameter of shaft | 76mm | |
| Shaft material | High grade 45# steel | |
| Drive type | Chain transmission | |
| Forming speed | 0-15m/min | |
| Main power | 5.5KW | |
| Cutting Device | Cutting type | Hydraulic cutting |
| Cutting Die Material | Cr12Mov steel, HRC58-62 | |
| Cutting power | 3KW | |
| CuttingTolerance | 10m1.5mm | |
| Encoder | OMRON Brand | |
| PLC Electrical Control System | PLC | PANASONIC Brand |
| Invert |
