1060mm Trapezoidal Roof Sheet Roll Forming Machine With C r 12 Cutting Blade

1060mm Trapezoidal Roof Sheet Roll Forming Machine With C r 12 Cutting Blade thumbnail-1
1060mm Trapezoidal Roof Sheet Roll Forming Machine With C r 12 Cutting Blade photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TECHWELL
Place of Origin:
China
Model Number:
TW-RWM
Contact Supplier Request Quote Chat Now
Techwell Machinery Company
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TECHWELL
Place of Origin China
Model Number TW-RWM
Delivery Time:55-65 working days
Certification:CE

1060mm Trapezoidal Roof Sheet Roll Forming Machine With C r 12 Cutting Blade



  Characteristic of Trapezoidal Roof Sheet Roll Forming Machine

This Trapezoidal Roof Sheet Roll Forming Machine can rollform iron steel trapezoidal roofing sheet. After roll formed by this roof roll forming machine, the surface of metal roofing is very smooth and beautiful without any scratch on the surface of roofing sheets. The Trapezoidal Roof Profile Roll Forming Machine is with fully automatic control system with PLC. Easy operation: Key in the length and quantity on the control panel. We also can do a custom roll forming machine, we can design machine according to your specifications and profile drawings.

  Specifications of Trapezoidal Roof Sheet Roll Forming Machine

 Item  Trapezoidal Roof Sheet Roll Forming Machine
 Coil Material  Thickness  0.3-0.8mm
 Coil width  Custom-made, 1000mm or 1200mm or 1250mm
 Yield Strength             250-350 Mpa
 Material  PPGI, Color Steel, GI.
 Decoiler / Uncoiler  Uncoiler Type  Manual or Hydraulic or Auto Type
 Coil Width  Max. 1250mm
 I.D  508-610mm
 O.D  Max. 1500mm
 Trapezoidal Roll Forming Machine    Forming Stations  16-18 Stations ( Depend on Profiles )
 Roller material   45# steel, surface coated with 0.05mm hard  chrome
 Diameter of shaft   76mm
 Shaft material  High grade 45# steel
 Drive type  Chain transmission
 Forming speed  0-15m/min
 Main power  5.5KW
 Cutting To Length Device                         Cutting type  Hydraulic cutting
 Cutting Die Material  Cr12Mov steel, HRC58-62
 Cutting power  3KW
 CuttingTolerance  10m1.5mm
 Encoder  OMRON Brand
 PLC Electrical Control System  PLC                                    PANASONIC Brand
 Inverter  YASKAWA Brand
 Touch screen  PANASONICE
 Operation type  Touch screen & Button
 Hydraulic Station  Hydraulic station  Famous Chinese brand
 Support Tables  Table type  Simple nonpower type
 Function  To support the finished panels

  Maintenance of Trapezoidal Roofing Sheet Roll Forming Machine

Daily maintenance plays an very importance role in extending the operation time and of roof wall sheet roll forming machine and the good quality finished roof wall panel. The following points should be part of the machine\'s daily production and usage routine.

Regularly lubricated the outside parts of the trapezoidal roofing sheet roll forming machine, such as the driving chain... Regularly brush the surface of roller, particularly when working outside. If you do not use the trapezoidal sheet panel forming machine in a long time, you should apply luricating oil on the roller surface, make sure you clean it for next time running machine. If the trapezoidal roofing sheet roll forming machine is not operated in a long period, should cover it with plastic film, to avoid getting rain or dust on the machine, or avoid the machine becoming dampt, especially the PLC electric control board. Make sure the cu
