Single Port 1x1 Rj45 8 Pin Connector Rj45 With Internal Magnetics

Keyouda Electronic Technology Co.,ltd,
Single Port 1x1 Rj45 8 Pin Connector Rj45 With Internal Magnetics thumbnail-1
Single Port 1x1 Rj45 8 Pin Connector Rj45 With Internal Magnetics photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
DGKYD
Place of Origin:
China
Model Number:
KRJ-138NL
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name DGKYD
Place of Origin China
Model Number KRJ-138NL
Delivery Time:Lead-time 7days
Certification:GP ROHS SGS ISO9001

1.Type: 8 pin rj45 connector

2.TAB direction: Down

3.Port:Single

4.Shieded:YES

5.LEDS:YES

6.EMI finger:YES

7.Length: 21.3mm

Single Port 1x1 Rj45 8 Pin Connector Rj45 With Internal Magnetics

Descriptions:

＊ 10/100Base-Tx RJ45 single port 1X1 Vertical with LEDS with side entry

＊ Single port 1X1 Tab-Down RJ45 with internal magnetics

＊ Internal magnetics are 100% electrically tested for HI-POT and functionality

＊ Suitable for CAT5&6 fast Ethernet Cable or better UTP

＊ 350uHminimum OCL with 8mA bias current

＊ High performance for maximum EMI suppression

＊ Minimum 1500Vrms isolation per IEEE 802.3 requirement

＊  ROHS-6 peak wave solder temperature rating 260℃

＊ Operating temperarure range :0℃ to +70℃

＊ Storage temperature range :-40℃ to +85℃

＊ Number of positions:8

＊ Number of contacts loaded:8

＊ Shielded:YES

＊ Rohs compliant

＊ Length:21.3mm

＊ LEDS:YES

＊ EMI:YES

＊ LEFT:Green,RIGHT:Yellow

＊ Usage:KRJ-138NL

2.ELECTRICAL SPECIFICATIONS @25℃

2.1 OCL :P(1-2)=P(3-6)=350 uH Min. @ 100 KHz, 100mV,with 8 mA DC Bias .

2.2 L.L:P(1-2)=P(3-6)= 0.5uH   Max. @ 100 KHz, 100mV

2.3 Cw/w: 35PF Max. @ 100 KHz, 100mV

2.4 Turn Ratio : P(1-2):J(1-2)=1CT:1CT±3%

                           P(3-6):J(3-6)=1CT:1CT±3%

2.5 DCR : 1.2Ω  MAX.

                 J(1-3):J(2-6)=J(4-7)=J(8-6)=150Ω

2.6 Polarity:  P1&J1;P3&J3   In-Phase.

2.7 Insertion Loss :-1.1dB Max @0.3~100MHz

2.8 Return Loss : -16 dB MIN  @1-30 MHz

                -14.4  dB MIN @40MHz

                -13.1  dB MIN @50MHz

                -12  dB MIN @60-80MHz

2.9 Cross Talk  : -35 dB MIN. @1~100 MHz

2.10 DCMR  : -25 dB MIN. @1~100 MHz

2.11Isolation HI-POT:  P(1-2-3-4-5-6-7-8) TO J(1-2-3-6-4-5-7-8)@1500Vrms/

    1mA Max/ 2SEC.

Material specifications:

＊ Plastic core:Glass fiber filler PBT Black(UL94V-0)

＊ Contact:gold pin0.35mm thick phos bronze plated nickel then with 6u’gold

＊ PCB Terminal:Phosphor bronze ,Tail-Tin over Nickl

＊ Housing:Phenolic, PBT Black (UL94V-0)

＊ Metal shell:Copper Alloy ,Tin and Nickel plated
