Corrugated Steel Roof Tile Press , Door Rail Cold Roll Forming Equipment

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HRF		Place of Origin	China
Model Number	HRF413.-41.3

Delivery Time:70 days
Certification:CE

41.3x41.3 Door Rail Forming Machine with on-line punching

Descrition:

1: The strut product is used widely to garage door rails

2. It has the feature With stable operation,low noise and high production performance

3: we adopt wall panel structure or heavy stands structure and I beam welded with which the machine is robost and strong

4: We adopt 11KW motor with speed reducer ,made in China and Yaskawa speed inverter made in Japan

5: we use Omron encoder to measure the length and control the length tolerance within 1.5mm

6: We absorb the technology from Spain on the cutting system and after cutting there is no burr

7: We exported this door rail forming machine to Europe,Malysia ,Philippines and so on and gained good reputation from the customers

Applications:

Door rails

Rails

Garage door rails

Specifications:

1. Profile Drawing:

2. Holes punching size:

4. Process flow:

Motorized-decoiler -- feeding -- leveling - hydraulic punching - Forming - Hydraulic cutting - 6M trasmission table

NO.	Name	Quant.	Remark
1	Motorized decoiler	1	3T
2	Main forming Machine unit	1	22 forming stations Cast iron stands Gearbox drive 22KW motor made in China
3	Turkish head	1 set	It can make the product straight
4	Hydraulic cutting	1	Material GCr15,HCR58-62 Hydraulic power 7.5kw
5	Hydraulic pre-punching	1 set	1) stop-to-punch 2) 1 set of holes punching mould
6	Cutting blade	1set	Cr12
7	6M Run-out table	1	Steel frame with Rollers Pneumatic pushing and drop the product
8	Electric control cabinet	1	1) PLC control,Siemens 2) Yaskawa inverter ,made in Japan 3) Omron encoder ,made in Japan
9	Cooling&lubrication system	1
