PVC Plenum Fire Alarm Cables 18 AWG 4C Shielded Red Cables

PVC Plenum Fire Alarm Cables 18 AWG 4C Shielded Red Cables thumbnail-1
PVC Plenum Fire Alarm Cables 18 AWG 4C Shielded Red Cables photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
KINGTONE OR OEM
Place of Origin:
China
Model Number:
FPLP 18 AWG
Contact Supplier Request Quote Chat Now
Kingtone Electronics Company
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name KINGTONE OR OEM
Place of Origin China
Model Number FPLP 18 AWG
Delivery Time:15 days
Certification:ISO,CE,RoHS,UL

KT1427 Fire Alarm Cables 18 AWG FPLP-CL2P PVC Insulation Plenum

Quick Details

FPLP 18 AWG Fire alarm cable Solid Copper conductor  unshielded types: 4C shielded types: 4C Plenum PVC 500ft , 1000ft Fire power limited cable

Description

KINGTONE ELECTRONICS is the leading manufacturer of fire alarm system cables for the fire protection industry. Our innovative product line includes all power-limited cables for use in the NEC Article 760.
NATIONAL ELECTRIC CODE (NEC) ARTICLE 760: NEC Article 760 covers the installation of wiring and equipment of fire alarm systems,including all circutis controlled  and powered by the fire alarm system.
These systems are defined in the NEC as \" The portion of wiring system between the load side of the overcurrent devices or the power-limited supply and the connected equipment of all circuits powered
and controlled by the fire alarm system.\"
Type FPLP-FPLP power-limited fire alarm cable is listed by the NEC as being suitable for usein ducts,
plenums and other space used for enviromental air. All FPLP cable are listed as having adequate
fire resistant and low-smoke producing characteristics and must pass both UL 1424
and UL stiener tunnel test 910
KT1427 Fire Alarm Cables 18 AWG FPLP-CL2P
PVC Insulation Plenum
Application
Indoor for:
Audio Circuits
Control Circuits
Initiating Circuits
Notification Circuits

Properties
Temperature Rating:    \'-20 to 75℃
Operating Voltage:       300 Volts max.
Flame Rating:              UL 910,NFPA 262,C(UL) FT6
Insulation & Jacket:      Plenum PVC

Unshielded types
Conductors NOM.THICKNESS(MM) Nominal0.D.  Capacitance Impedance DC Resistance
Number Solid Insulation Jacket Inch pf/ft Ohms Ohms/M\'
2 18 AWG 0.007\" 0.015\" 0.136\" 28 68 6.5
4 18 AWG 0.007\" 0.015\" 0.157\" 28 68 6.5
Shielded types
Conductors NOM.THICKNESS(MM) Nominal0.D.  Capacitance Impedance DC Resistance
Number Solid Insulation Jacket Inch pf/ft Ohms Ohms/M\'
2 18 AWG 0.007\" 0.015\" 0.140\" 68 30 6.5
4 18 AWG 0.007\" 0.015\" 0.168\" 62 30 6.5
6 18 AWG 0.007\" 0.015\" 0.198\" 62 30 6.5
  Drain Wire     22 AWG Solid Tinned-Copper
  Shield     0.001\" thick Aluminum/Mylar

Color
Number Description
2 Blk,Red
4 Blk,Red,Ylw,Grn
6 Blk,Red,Ylw,Grn,Brn,Blu
