Security PVC Insulation Fire Alarm System Cable , 16 AWG Shield Cable

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	KINGTONE OR OEM		Place of Origin	China
Model Number	FPLR 16 AWG

Product Description

Delivery Time:15 days
Certification:ISO,CE,RoHS,UL

Security PVC Insulation Fire Alarm System Cable , 16 AWG Shield Cable

Quick Details

FPLR 16 AWG Fire alarm cable Solid Copper conductor unshielded types: 2C/4C shielded types: 2C/4C RISER PVC 500ft , 1000ft Fire power limited cable

Description

KINGTONE ELECTRONICS is the leading manufacturer of fire alarm system cables for the fire protection industry. Our innovative product line includes all power-limited cables for use in the NEC Article 760.

NATIONAL ELECTRIC CODE (NEC) ARTICLE 760: NEC Article 760 covers the installation of wiring and equipment of fire alarm systems,including all circutis controlled and powered by the fire alarm system.

These systems are defined in the NEC as \" The portion of wiring system between the load side of the overcurrent devices or the power-limited supply and the connected equipment of all circuits powered

and controlled by the fire alarm system.\"

Type FPLR- FPLR power-limited fire alarm riser cable is listed as being suitable for use in a vertical run

in a shaft or from floor to floor.All FPLR cables are listed as having fire-resistantcharacteristics capable of preventing fire from traveling from floor to floor.Riser cables must pass both UL test 1424

and the Vertical riser test UL 1666.

KT1423 Fire Alarm Cables 16AWG FPLR-CL2R PVC Insulation Riser
Application
Indoor for:
Audio Circuits
Control Circuits
Initiating Circuits
Notification Circuits

Properties
Temperature Rating: \'-20 to 75℃
Operating Voltage: 300 Volts max.
Flame Rating: UL 1666(Riser),C(UL)FT4
Insulation & Jacket: PVC

Shielded types
Conductors	NOM.THICKNESS(MM)	Nominal0.D.	Capacitance	Impedance	DC Resistance
Number	Solid	Insulation	Jacket	Inch	pf/ft	Ohms	Ohms/M\'
2	16 AWG	0.008\"	0.015\"	0.166\"	46	34	4.1
4	16 AWG	0.008\"	0.015\"	0.195\"	46	34	4.1

Drain Wire	20 AWG Solid Tinned-Copper
Shield	0.001\" thick Aluminum/Mylar

Color
Number	Description
2	Blk,Red
4	Blk,Red,Ylw,Grn

Order Informations:
Print	KINGTONE KT1423 ×C14 E×××××××(UL) FPLR OR CL2R SUN RES(ROHS) ××××FT DEVICE/ZONE A B C D E F 1 2 3 4 5 6 7 8 9
Packing	1000FT/Pull Box, 1000FT/Spool, Pallet

Competitive Advantage:

1, From raw materials to final products, we perform intense quality checks to maintain our product quality:

A, Incoming material inspected by QC.

B, Manufacturing Process Control

C: Workers trained daily/weekly/monthly

D: Work instructions manual at each work station

E: 5S system implemented

F: Machine maintenance procedure

G: Quality Control and Final Inspection

The QC staff will check the material, process product

and final product according to the specification or test procedure.
