Double Colour Striped Plastic Film Blowing Machine For Low Density Polyethylene
- T/T L/C D/P D/A
- 7 days
You May Like
-
Professional High Speed LDPE Film Blowing Machine 40-70kg/h
-
High Speed Mini Pe Plastic Film Blowing Machine 11kw 22kw 30-50kg/h
-
48kw Automatic Pe Bubble Film Making Machine With 1000-1500mm Width
-
380V HDPE Bubble Plastic Film Blowing Machine With Single Rewinder CE
-
50HZ 300W Single Head Auger Filling Machine 1500-3000 Bags / Hour
-
Two Screw Double Layer Plastic Film Blowing Machine With Rotary Die Head
Product Details
| Place of Origin | China | |
| Model Number | SJ-40Dx2x600 |
Product Description
Certification:CE
Quick Detail:
CE Certificate 380V 50Hz HERO BRAND 580-1500mm width Double color LDPE HDPE filmDescription:
Characteristics:
The cylinders and the screw stems of model SJ-40D¡Á2 extruder are made of high-quality alloy steel with optimum hardness and strong corrosion resistance after precision finishing and nitrogen treatment.FM-600 auxiliary machine can be freely adjusted within the limits of 700mm according to the technologjcal requirements of different materials, and has is fitted with a plug-in plate mechanism for making vest bag ,The coiling unit adopts torque motor to keep proper tension and make rolling even and roll-changing easy.
Use:
It is used for blowing the various plastic film of low density polyethylene(LDPE) and high density polythylene(HDPE) colour striped plastic film, etc, Which are widely used for packing food, fruit,garments, textile, dailly necessities and other civil and industral products
Specifications:
Main Technical Variables:
|
Model |
SJ-40Dx2x600 |
|
Screw Diameter |
40mmx2 |
|
Screw Ratio |
L/D28:1 |
|
Screw Speed |
10-100r/min |
|
Power of Main Motor |
11KW |
|
Main Output |
30kg/h |
|
Max.Folding Width of Film |
580mm |
|
Single-sided Thickness of Film |
0.006-0.06mm |
|
Lifting Range of Auxiliaty Machine |
2200kg |
|
Overall Dimensions |
3800x2000x2800mm |
About Us :
HERO PLASTIC PLASTIC MACHINE CO.,LTD SINCE 1985 found at the ground south along the sea (Namely China packing City ), is a two more than ten years,enterprise specializing in making complete set of series soft packing equipments.Now the company collect an elitist for been gaged inning the design,manufacturing,examining,debugging,The whole staff of enterprise \"Striving for Survival by Quality, Striving for Development by Creative\" encourage bottom,under the concern and support of the commerce colleague,pass by not the gradually become to have to completely design to develop the ability, forerunner the production the craft with the stubborn at full split,complete process the equipments,strict examination means,science the factory hoist that manage.
Facing the new century shangwang person with the acute market competition,and fix attention on the future and have a foothold creative,constants identical.Insist\"Quality Frist,Customer Supreme\"for operate the aim.With the machine product of the high quality,on time the thoughtful service create to set up the good brand,then repay the large customer to support shangwang print machine.Our product is distributed all over the country,and exported to southeast Asia,Middle-east,Russia,South America,Africa,and the product was charmed the client.
