Help CenterHigh Speed Mini Pe Plastic Film Blowing Machine 11kw 22kw 30-50kg/h
Related Products
-
48kw Automatic Pe Bubble Film Making Machine With 1000-1500mm WidthUS$ 1 - 10000MOQ: 1 Square Meter -
380V HDPE Bubble Plastic Film Blowing Machine With Single Rewinder CEUS$ 1 - 10000MOQ: 1 Set
-
Two Screw Double Layer Plastic Film Blowing Machine With Rotary Die HeadUS$ 1 - 10000MOQ: 1 Set
-
PE Film Rotary Die Head 3 Layer Blown Film Line 15kw 380VUS$ 1 - 10000MOQ: 1 Set
-
600-1200mm 11kw PE Head Blown Film Extrusion Machine For Hdpe LdpeUS$ 1 - 10000MOQ: 1 Piece
Certification:CE
Quick Detail:
CE Certificate 380V 50Hz HERO BRAND 30-50kg/h Mini Size LDPE HDPE LLDPE3 Year Warranty
Description:
Use: It applies to blow various LDPE, HDPE and LLDPE plasticfilms, widely applying to food, fruit, clothing, textile, vesttype bag and etc. Packing of civil industrial products.
Feature: Mode SJ45-50 squeezing machine is adopted rotatory die head,machine tube is adopted 38CrMoAl,having the best hardness and corrosion-resisting performance after nitrogen treatment and precision processing.
FM-600 auxiliary machine can adjust and operate freely within the range of 700mm in accordance with the technological demand of different materials, and having package board mechanism which can make vest type bag.
Rolling up device with double-drawing in and do-uble cutting ope, its power is adopted moment motor, with friction plate,it can keep suitable tension, drawing in and rolling up in good order, easy to change roll.
Specifications:
Technical Parameters:
|
Power |
22KW |
|
Assistance Machine |
0.75KW |
|
Heating |
11KW |
|
Die-Head |
Φ30-80 Choose freely mm |
|
Screw Diameter |
Φ45/50 Choose freely mm |
|
Screw L/D Ratio |
L/D 28:1 |
|
Screw Speed |
10-100r/min |
|
Max Ouput |
30-50kg/h |
|
Film Thickness |
0.008-0.10 mm |
|
Film Width |
50-600 mm |
|
Dimension |
2200*1900*2200MM |
|
Weight |
2T |
About Us :
HERO PLASTIC PLASTIC MACHINE CO.,LTD SINCE 1985 found at the ground south along the sea (Namely China packing City ), is a two more than ten years,enterprise specializing in making complete set of series soft packing equipments.Now the company collect an elitist for been gaged inning the design,manufacturing,examining,debugging,The whole staff of enterprise \"Striving for Survival by Quality, Striving for Development by Creative\" encourage bottom,under the concern and support of the commerce colleague,pass by not the gradually become to have to completely design to develop the ability, forerunner the production the craft with the stubborn at full split,complete process the equipments,strict examination means,science the factory hoist that manage.
Facing the new century shangwang person with the acute market competition,and fix attention on the future and have a foothold creative,constants identical.Insist\"Quality Frist,Customer Supreme\"for operate the aim.With the machine product of the high quality,on time the thoughtful service create to set up the good brand,then repay the large customer to support shangwang print machine.Our product is distributed all over the country,and exported to southeast Asia,Middle-east,Russia,South America,Africa,and the product was charmed the client.
