Electric Brushless DC Motor 6 Lead 22mm with 24 Volt and three Phase
22BLDC motor Model Number:JK22RBL Phase: 3 Phase Lead Wire (No.): 4 or 6 wire Step Angle: 1.8°/ 0.9° Motor Height: 22mm Number of poles:8 Peak current :1.1 - 1.5 A Rated Voltage: 24 V Power: DC Peak Torque: 21 mN.m -50mN.m Function: Control Speed: Low or High speed Usage: Industrial Shape: Tubular Certification: CE, ROHS, ISO900122mm brushless dc motor /22BLDC motor/ Chinese supplier for brushless motor/
Description:
22mm brushless dc motor , BLDC MOTOR 24v dc brushless motor, 22mm dc brushless motor,
|
GENERAL SPECIFICATIONS |
ELECTRIC CONNECTION |
|
Winding type |
Star |
|
Hall effect angle |
120 degree electrical angle |
|
Shaft run out |
0.025mm |
|
Radial play |
0.02mm@450g |
|
End play |
0.08mm@450g |
|
Max. radial force |
10N @ 10mm from the flange |
|
Max. axial force |
2N |
|
Insulation class |
Class B |
|
Dielectric strength |
500VDC for one minute |
|
Insulation resistance |
100MΩMin., 500VDC |
Applications:
Use for CNC machine .
Electric Specifications:
|
Model |
JK22RBL45 |
JK22RBL68 |
|
Number of poles |
8 |
8 |
|
Number of phase |
3 |
3 |
|
Rated voltage VDC |
24 |
24 |
|
Rated speed RPM |
4600 |
3500 |
|
Continuous stall torque mN.m |
9.6 |
26.4 |
|
Rated torque mN.m |
8 |
22 |
|
Rated power W |
3.8 |
8 |
|
Peak torque mN.m |
21 |
50 |
|
Peak current A |
1.1 |
1.5 |
|
Line to line resistance ohms |
23 |
11.8 |
|
Line to line inductance mH |
6.2 |
4.2 |
|
Torque constant mNm/A |
30.2 |
35.5 |
|
Rotor inertia g.cm2 |
0.66 |
1.32 |
|
Body length mm |
45 |
68 |
|
Mass Kg |
0.07 |
0.12 |
Dimensions:
(Unit=mm)
