pcd grinding machine
PCD, PCBN, CVD, tungsten, carbide tools grinding machine
1.Main Technical Parameters
1-1.Spindle and Grinding Wheel
1)Diameter of Grinding wheel:150mm
2)Direct Drive Spindle with Water Cooling:3KW
3)RPM of Grinding Spindle:0~3,000RPM
4)Changeable Clearance Angle:-5°~25°
5)Grinding wheel center hole:40mm
6)Spindle Center Height:150mm
1-3.CCD Monitoring System
1)Max Magnification of Optical Microscope:4 times
2)Magnification of CCD Measuring System :80times
3)19Industrial Displayer:19"
4)CCD Image Resolution:1280*1024
1-4.Feed and Rotation System
1)Compressor of Air Braking on Rotation Axis:6bar
2)Tool rotation (B axis) controlled by PLC. Can be switched to manual mode:LCD input
3)Horizontal Transverse (Y Axis) Driven by Air:70mm
4)Linear Encoder Resolution (X Axis and Y Axis):0.001mm
1-5.Power Supply and Dimensions
1)Coolant Tank with Filter Paper:about70L
2)Electrical Supply:12Kw
3)Voltage Requested:380V/Three phase /50Hz
4)Overall Dimensions L-W-H:1700-1150-1970mm
5)Weight With Coolant Tank:2000Kg
3.Offer validity :3 months
4.Port:Tianjin,Qingdao
5. Delivery time: 45 work days after sign contract, if any special requirement can be consulted
6.skype:nina-superhardtools
