Help CenterEsp Cable
Related Products
|
Type |
Name |
|
QYPF(Y) |
Polypropylene(PP)insulated butadiene PVC compound sheath bare steel tape armored with interlock ESP flat(round) power cable |
|
QYPN(Y) |
Polypropylene(PP)insulated butadiene rubber inner sheathed bare steel tape armored with interlock ESP flat(round) power cable |
|
QYPFI |
PP insulated UV protection compound sheath bare steel tape armored with interlock ESP flat power cable |
|
QYYFQ |
Polyimide F46 compound film sintering/F46 compound insulated lead inner sheath bare steel tape armored with interlock ESP flat power cable |
|
QYEQ(Y) |
EPR insulated lead inner sheath bare steel tape armored with interlock ESP flat(round) power cable |
|
QYEN(Y) |
EPR insulated butadiene rubber inner sheath bare steel tape armored with interlock ESP flat(round) power cable |
|
QYYFTT |
Polyimide F46 compound film/F46 compound insulated fluorine plastic inner sheath bare steel tape armored with interlock ESP flat power cable |
Range of Production
|
Type |
Sectional Area mm2 |
No. of Cores |
|
All Types |
10-42 mm2 |
3 |
Main Technical Parameter
|
Voltage Class |
Imbalance Rate of DC Resistance % |
length tolerance |
DC Leakage Resistance 15.6℃Ω/km |
Voltage Proof No breakdown in 5
|
Insulation Resistance at 20℃ |
||||||||||||||||||||||||||||||||||||
|
3kV |
≦2 |
5‰ |
≦15uA/km |
27kV/5min |
≧2500 |
||||||||||||||||||||||||||||||||||||
|
6kV |
≦2 |
5‰ |
≦15uA/km |
35kV/5min |
≧2500 |
Send Inquiry to This Supplier
