Wheel Loader ZL30FS With Fork

Rated load: 3000kg
Total weight:7000kg

Dim.: 6900*2050*2950 mm

Engine: 83kw Diesel Engine

Automatic Transmission

If you have any questions, please feel free to contact Ms.Lisa Liu: loadercnAT126DOTcom
Parameters:

1 .Rated Load                                                          3000 kg

2. Total Weight                                                        7000 kg

3. Rated Bucket Capacity                                   1.5-1.9 CBM

4. Max. Tractive Force                                          61 KN

5. Max. Breakout Force                                                ≥ 72 KN

6. Max. Gradeability                                             38°

7. Max. Dumping Height                                              3500 mm

8. Max. Dumping Reach                                                         1300 mm

9. Raising Time                                                        ≤ 6.0 s

10. Total Cycle Time                                              ≤ 11.5 s

11. Overall Dimensions (L x W x H)                  6900*2050*2950 mm

12. Min. Turning Radius                                      3800 mm

13. Engine Model                                                    WEICHAI HUAFENG 4RMAZG Turbocharged DIESEL Engine

YUCHAI YCD4J22T-115 Turbocharged DIESEL Engine

14. Engine Type                                                       Four-cylinder, Inline, Water-cooled, Four-stroke Diesel Engine

15. Engine Rated Power                                       83 kW / 85 kW

16. Engine Rated Speed                                       2400 rpm

17. Engine Min. Fuel Consumption Ratio         ≤ 210 g/kW•h

18. Transmission System                                               ZL280 Split Hydraulic Torque Converter

19. Gear Shift                                                          1 Forward, 1 Reverse, 1 High Speed, 1 Low Speed

20. Max. Speed                                                       25 km/h

21. Model of Drive Axle                                        ZL20 Hub Reduction Axle (big)

22 . Wheel Tread                                                     1650 mm

23. Wheel Base                                                       2600 mm

24. Drive Mode                                                       4-wheel Drive

25. Hydraulic System Working Pressure          20 Pa

26. Fuel Tank Capacity                                          100 L

27. Service Brake                                                    Foot Pedal Vacuum Booster, Air Over Hydraulic Caliper Disc Brake on 4 Wheels

28. Parking Brake                                                   Hand Lever Flexible Shaft Controlled Disc Brake

29. Tire Type Specification                                   16/70-24-16PR

30. Front Tire Pressure                                         0.40 Mpa

31. Rear Tire Pressure                                          0.35 Mpa
