Mini Wheel Loader New Model ZL08F With Log Grab

Name: Mini Wheel Loader New Model ZL08F With Log Grab
Brand: Guohua
SKU: 148049446
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Guohua

Place of Origin:

China

Model Number:

ZL08F

Qingzhou Guohua Construction Machinery Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name Guohua

Place of Origin China

Model Number ZL08F

Using 8.25-16-14PR ultra-wide tyres to increase the stability of the whole machine;
Running system adopts mechanical drive, and the power transmission mode adopts belt transmission ;
Power system adopts CHANGCHAI L28 single-cylinder engine to make the machine energy saving and environmentally friendly with high working efficiency;
4-wheel drive and fully hydraulic steering make this mini wheel loader light and flexible;
The gear shift of this small wheel loader has 2 forward and 1 reverse shifts with high and low speed;
This compact wheel loader can be equipped with optional quick hitch (quick coupler), and this quick hitch enables this compact wheel loader to change quickly among multiple attachments, such as hay grapple, grass grab, log grab, timber grapple, pallet fork, bale grapple, four-in-one bucket, straight snow blade, V-shaped snow blade, snow bucket, drum grab and barrel grapple, etc.

Model: ZL08F
	Item	Parameters
Performance	1 .Rated Load	800 kg
2. Total Weight	2400 kg
3. Rated Bucket Capacity	0.3 m³
4. Max. Tractive Force	28 KN
5. Max. Breakout Force	≥ 21 KN
6. Max. Gradeability	38°
7. Max. Dumping Height	2680 mm
8. Max. Dumping Reach	900 mm
9. Raising Time	≤ 4.0 s
10. Total Cycle Time	≤ 9.0 s
11. Overall Dimensions (L x W x H)	480016402550 mm
12. Min. Turning Radius	3000 mm
Engine	13. Model	CHANGCHAI L28
14. Type	Single-cylinder, Horizontal, Water-cooled Evaporative, Four-stroke Diesel Engine
15. Rated Power	20 kW
16. Rated Speed	2200 rpm
17. Min. Fuel Consumption Ratio	≤ 244.8 g/kW·h
Transmission	18. Mode	Mechanical Shift
19. Gear Shift	2 Forward, 1 Reverse, High & Low Speed
20. Max. Speed	25 km/h
Drive Axle	21. Model of Axle	50 Drive Axle
22. Wheel Tread	1330 mm
23. Wheel Base	2130 mm
Drive	24. Mode	4-wheel Drive
Hydraulic System	25. System Working Pressure	16 Pa
26. Fuel Tank Capacity	60 L
Brake System	27. Service Brake	Drum Brake
Tyre	28. Type Specification	8.25-16-14PR
29. Front Tyre Pressure	0.40 Mpa
30. Rear Tyre Pressure	0.35 Mpa
