Sftp Cat5e Lan Cable

Name: Sftp Cat5e Lan Cable
Brand: lasun,CCB
SKU: 148026420
Availability: InStock

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

lasun,CCB

Place of Origin:

China

Model Number:

Cat5e SFTP

Shenzhen CCB Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name lasun,CCB

Place of Origin China

Model Number Cat5e SFTP

Shielded Twisted Pair Cable SFTP, category 5e, 4 pairs, solid

Specifications:
Meets ANSI/EIA/TIA 568-B.2 requirements Fire protection – CM The cable meets UL 1581 VW-1 fire safety standard

Description:
Shielded Copper cable, 4 pairs, category 5e, solid Shield: aluminum foil and wire braid The cable meets UL 444 UL 1581 fire safety standard

Materials:
Conductive material: wire made of soft annealed electrolytic copper Conductor insulation: HDPE The cable jacket: PVC An aluminum tape shield is helically applied over the cable core with a minimum overlap of 25% or 5 mm (0.19"), thickness – 0.025 mm (0.001"), width – 20 mm (0.78"), and braid of 16 tinned Copper wires

Technical characteristics:
Application: horizontal wiring in LAN Conductor diameter: 0.02" (0.51 mm) (24 AWG) Insulated conductor diameter: 0.035" ± 0.001" (0.9 ± 0.02 mm) Outer cable diameter: 0.24" +- 0.012" (6.1 +- 0.3 mm) Shield: aluminum foil and tinned copper wire braid Jacket thickness: 0.015" (0.4 mm) Minimum bend radius: 4 outer cable diameters Conductor elongation: 14% minimum Drain wire diameter: 0.019" (0.5 mm) Operating temperature: -4°F to +167°F (-20°C to +75°C) Weight per 1000 ft: 32.9 lbs (14.9 kg) Standard package: 1000 ft (305 m)

Electrical characteristics
Frequency, MHz	RL	Attenuation, dB	NEXT, dB	PSNEXT, dB	ELFEXT, dB	PSELFEXT, dB
0.772	-	1.8	67.0	64.0	-	-
1.0	20.0	2.0	65.3	62.3	63.8	60.8
4.0	23.0	4.0	56.3	53.3	51.7	48.7
8.0	24.5	5.8	51.8	48.8	45.7	42.7
10.0	25.0	6.5	50.3	47.3	43.8	40.8
16.0	25.0	8.2	47.3	44.3	39.7	36.7
20.0	25.0	9.3	45.8	42.8	37.7	34.7
25.0	24.3	10.4	44.3	41.3	35.8	32.8
31.25	23.6	11.7	42.9	39.9	33.9	30.9
62.5	21.5	17.0	38.4	35.4	27.8	24.8
100.0	20.1	22.0	35.3	32.3	23.8	20.8

Max conductor resistance at 20°C (68°F)	9.38 Ohm/100 m (2.9 Ohm/100 ft)
Max Resistance Unbalance	5%
Max pair-to-ground capacitance unbalance	330 pF/100 m (101 pF/100 ft)
Characteristic Impedance at 0.772-100 MHz	85-115 Ohm
Mutual capacitance	5.6 nF/m (1.7 nF/ft)
Spark Test	2.5 kV
