Cat.5e Lan Cable

Name: Cat.5e Lan Cable
Brand: lasun,CCB
SKU: 148026136
Availability: InStock

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

lasun,CCB

Place of Origin:

China

Model Number:

Cat5e UTP

Shenzhen CCB Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name lasun,CCB

Place of Origin China

Model Number Cat5e UTP

Unshielded Twisted Pair Cable (UTP), category 5e, 4 pairs, Solid, LSZH

Description:
Unshielded Copper cable, 4 pairs, category 5e, solid Application: horizontal wiring in LAN Cable is used for indoor installation Meets UL444/UL1581 fire safety standard and TIA/EIA 568A

Technical characteristics:
Conductor: annealed bare copper 0.51+-0.01 mm, 24 AWG Insulation: HDPE, minimum average thickness 0.19 mm, minimum thickness at any point 0.18 mm Insulated conductor diameter: 0.9+-0.01 mm Identification: - Blue-White/Blue, - Orange-White/Orange, - Green-White/Green, - Brown-White/Brown 4 twisted pairs Jacket: LSZH, minimum average thickness 0.45 mm, minimum thickness at any point 0.4 mm Outer cable diameter: 5.1+-0.2 mm Minimum bend radius: 8xØ while installation, 6xØ while vertical cabling, 4xØ while horizontal cabling Standard package: 18.5x37.5x36.5 cm (WxHxD) - 305 m Weight of cable without package: 9.7 kg Weight of cable with package: 10.5 kg Weight per 1 km: 31.8 kg Rating temp: 75°C Flame test: CM Standard: UL444/UL1581, TIA/EIA 568A

Electrical characteristics:
Frequency, MHz	RL	Attenuation, dB	NEXT, dB	PSNEXT, dB	ELFEXT, dB	PSELFEXT, dB
0.772		1.8	67.0	64.0
1.0	20.0	2.0	65.3	62.3	63.8	60.8
4.0	23.0	4.0	56.3	53.3	51.7	48.7
8.0	24.5	5.8	51.8	48.8	45.7	42.7
10.0	25.0	6.5	50.3	47.3	43.8	40.8
16.0	25.0	8.2	47.3	44.3	39.7	36.7
20.0	25.0	9.3	45.8	42.8	37.7	34.7
25.0	24.3	10.4	44.3	41.3	35.8	32.8
31.25	23.6	11.7	42.9	39.9	33.9	30.9
62.5	21.5	17.0	38.4	35.4	27.8	24.8
100.0	20.1	22.0	35.3	32.3	23.8	20.8

Conductor resistance at 20°C (68°F)	9.38 Ohm/100 m (2.9 Ohm/100 ft)
DC Resistance Unbalance	5%
Pair-to-Ground Capacitance Unbalance	330 pF/100 m (101 pF/100 ft)
Impedance 0.772-100 MHz	85-115 Ohm
Mutual Capacitance	5.6 nF/m (1.7 nF/ft)
Spark Test	2.5 kV
