Steel galvanized Cantilever dams, piers Climbing Formwork for retaining wall / cooling tower
1.Steel Climbing Formwork2.Cantilever formwork is used in dams, piers, retaining wall and cooling tower.
3.Surface: galvanize
Introduction:
Cantilever formwork is used in dams, piers, retaining wall and cooling tower etc.
The formwork can be moved freely as you request. The formwork can be inclined backward and forward. Max. angle: 30°.
Cantilever formwork is a kind of bracket lifted by tower crane. Easy to assemble, fast to construct, safe and simple to operate, this system is really a competitive formwork system and can bring the contractor good profit.
| ---3 levels platform |
| ---All levels platform and panel are connected together, lifted in one unit; |
| ---Panel can be retracted 65cm, and can be inclined; |
| ---Two different platform widths, two types of loadability platform, meet all project requirements; |
| ---Platform width: up platform, 1.2m |
| main platform, 2.4m |
| suspension platform, 1.2m; |
| --- Formwork system tie rod is not necessary. Concrete pouring height up to 4.0m. |
Cantilever formwork is used in dams, piers, retaining wall and cooling tower etc.
All the concrete side-pressure is borne by the anchors and the brackets. As there is no through-wall tie-rod, the concrete is very clean.
The formwork can be moved backward by 600mm for cleaning the formwork and fixing the reinforcing steel bar. Waler connector is used for connecting the form to ensure form alignment.
Form can be pushed to the already cast concrete by turning the adjust carriage to avoid concrete offset or leakage.
The formwork can be moved freely as you request. The formwork can be inclined backward and forward. Max. angle: 30°.
High standard elements can be widely used.
