Custom Strengthened Flat Toughened Safety Glass, Safety Tempered Glass With EN 12150
Specifications:
Thickness: 3-19mm
Color of tempered glass/toughened glass/strengthened glass: clear, brown, blue, green, grey, etc.
Max specification:
Flat tempered glass/toughened glass/strengthened glass: 3000*8000mm
Bent tempered glass/toughened glass/strengthened glass: 3000*5000mm, R=1500mm
Considering the characteristics of tempered glass/toughened glass/strengthened glass, glass size should be confirmed before making production. Once tempered glass size is confirmed, tempered glass/toughened glass/strengthened glass can not be made mechanical treatment any more, otherwise, tempered glass/toughened glass/strengthened glass will be broken.
3 - 19mm blue, green Toughened Safety Glass with resist heat effectively
Tempered glass/toughened glass/strengthened glass are made by forming compressive stress on the surface of the glass and heating the glass up to its intenerating temperature and then make the glass uniform cooling quickly. During the process of cooling, the exterior part of the glass is solidified because of the rapid cooling, while the interior part of the glass shrinks because of slow cooling, then forming compressive stress on the surface of the glass and tensile stress inside the glass, thus improving the intensity and heat stability of the glass.
Tempered glass/toughened glass/strengthened glass can be with holes or cutouts to process into tempered laminated glass, tempered insulated glass, etc.
Standard: EN 12150; ASTM 1048; BS 6206:1918; GB 15763.2-2005; AS/NZS 208:1996
Applications:
Tempered glass/toughened glass/strengthened glassis safety glass, which is widely used as window glass, door glass, curtain wall glass, fencing glass in buildings, hotels, curtain wall, etc.
Competitive Advantage:
Tempered glass/Toughened glass/Strengthened glass has a very good performance of anti-curve, anti-impact intensity, 3 to 6 times better than normal glass. Tempered glass/Toughened glass/ Strengthened glass can afford pressure over 95MPa on the surface. Tempered glass/Toughened glass/ Strengthened glass has high stability even under temperature change of 200-300 centi-degree, while normal glass can only afford change of 70-100 centi-degree. Tempered glass/Toughened glass/ Strengthened glass becomes small sand shape if tempered glass/toughened glass/strengthened glass is broken under big force, which guarantee safety and less loss.
Safety performance: Tempered glass/toughened glass/strengthened glasswill appearance hurtless obtuse angles when breakage.
Strength performance: Four times more than ordinary glass.
Heat stability performance: Three times more than ordinary glass, could bear the temperature change about 200°C .
1. Safety
2. Tempered glass/toughened glass/strengthened glasshas 4-5 times strength than ordinary glass
3. Hot stability
4. Generously satisfy with different clients’ requirement to meet different designs
|
Quality Standards |
|
GB 15763.2, Chinese standard. |
|
EN 12150.1, European standard. |
|
EN 12600, European standard. |
