Plastic Ptfe Film and Tape

Name: Plastic Ptfe Film and Tape
Brand: SenRong
SKU: 147666770
Availability: InStock

US$ 5 - 15 MOQ: 200 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

SenRong

Model Number:

SDFM1

Contact Supplier Request Quote Chat Now

Shandong Senrong New Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai Ningbo Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name SenRong

Model Number SDFM1

Specifications

Ptfe Films
High dielectric
chemical resistant
wide range of operation temprature

PTFE Films , PTFE membrane, ptfe porous membrane ,ptfe porous film, Virgin pure white ptfe plastic film .

1.Features:

PTFE resin is first moulded into billet and then skived . The PTFE resin skived sheet &tape are highly dielectric. Chemical resistantand not aging . They have a wide range of operation temperature.

2.Usage:

Lining ,sealing and oillesslubricating material and dielectric at any frequencies . Capacitor dielectric , wire isolation , electrical instrument isolation.

PTFE plates &belts:

3.Main properties:

Property	Unit	Result
Property	Unit	Chinese material	Import material
Apparent density	g/cm3	2.10~2.30	2.10~2.30
Tensile strength	Mpa	20	28
Crack elongation	%	250	300
Dielectric strength	Kv/mm	10	12

Specifications:

Property

Code name

Skived sheet

Thickness(mm):0.2-7mm

Width(mm)850.1000.1200.1500.1800.2000

Length(mm)>500

Skived tape

Thickness(mm):0.2-4mm

Width(mm):100-500

Length(mm): >1000

PTFE Film:

Specifications:

Item	Thickness	Thickness allowance	Width	Width allowance	Length (m)
High –density	0.030-0.100	±10%	30-90	±0.3	>10
Semi-density	0.050-0.100	±10%	60-90	±0.3	>5
Common	0.050-0.500	±10%	60-90	±2.0	>5
